Cub Cadet Lawn Mower - Manual (Page 5)

5
48" Fabricated Cutter Deck - Parts List for Figure 2
Ref.
No. Part No. Description Qty.
1 00003107 Cotter Pin, .125 Dia. x 1.0 2
2 00011925 Hex Cap Screw, 3/8-16, 3.75 2
3 01002010 Carriage Screw, 3/8-16 x 1.25 4
4 00012428 Lock Nut, Nylon Insert, 1/2-13 4
5 00013406 Hex Cap Screw, 5/16-18 x 3/4 1
6 00022560 Flange Lock Hex Nut, 3/8-16 46
7 00030633 Decal Rotating Blade 1
8 00030635 Decal Warning Shield Missing 2
9 01003254 Chute Deflector Rod 1
10 00083192 Idler Washer 1
11 01000343 Complete Wheel, 5.00 Dia 2
12 01000372 Carriage Bolt, 3/8-16 x .75 Lg 36
13 01000375 Roller Pin, 1/2 Dia x 7.31 Lg 1
14 01000385 Front Roller 3
15 01000398 Wheel Spacer 2
16 01000635 Hex Flange Lock Nut, 5/16-18 1
17 01000643 Carriage Bolt, 3/8-16 x 1 7
18 01001745 Pin, 5/8 Dia. x 1.2 Lg. 4
19 01003253 Torsion Spring, 0.4 ID x 2.16 LG 1
20 01002166 Decal, Danger Hands and Feet 2
21 01004751 Roller Rod 1
22 01004109 Bracket Stop Tension Rod 1
23 01004304 Hex Index Washer Screw, 3/8-16, .05 8
24 01009300 Fabricated Deck, Chute Bracket 1
25 01008644 Fabricated Deck Finger Guard 1
26 01004685 Fabricated Belt Support Cover 2
27 01008641 Left Hand Deck Bracket Assembly 1
28 01008812 48 Fabricated Deck Assembly 1
29 01005364 Fabricted Deck Roller Mount Bracket 3
30 01005260 Front Anti-Scalp Wheel Mount Bracket 2
31 01005256 Left Hand Front Roller Mount Bracket 1
32 01005258 Right Hand Front Roller Mount Bracket 1
33 01008635 Right Hand Deck Bracket Assembly 1
34 01005437 Outer Belt Cover Support Assembly 2
35 01006693 Deflector Chute 1
36 01008226 Deflector Chute Bracket 1
37 02000446 Right Hand Belt Cover 1
38 02000445 Left Hand Belt Cover 1
39 01005869 Latch Drawing, T-Handle 4
40 01001169 Roller 2
41 00017778 Phillip Head Screw, 10-32 16
42 00014608 Lock Nut, Nylon Insert, 10-32 16
43 01006087 Label 1
44 02000109 Pillow Block 2
45 00026313 Decal, 48" 2
