11
Brake Assembly - Parts List for Figure 5
Ref.
No. Part No. Description Qty.
1 741-0598 Hex Flange Bearing, .752 ID 2
2 00011459 Washer, 1/2 2
3 00012152 Lock Nut, Nylon Insert, 1/4-20 1
4 00012382 Hex Cap Screw, 5/16-18 x 1-1/2 2
5 00013092 Hex Cap Screw, 5/16-18 x 1.0 1
6 00022560 Flange Lock Hex Nut, 3/8-16 1
7 00027279 Nut, 7/16-14, Nylock 2
8 00071691 Spacer, Control Rod 1
9 01000371 Hex Cap Screw, 3/8-16 x 3-1/4 1
10 01000393 Flat Washer, .469 ID, .875 OD, .105 4
11 01000629 Screw, TT, 1/4-20, 0.75, Hex Index Washer 1
12 01000635 Nut, Lock, HexFlange, 5/16-18 4
13 01000723 Flat Washer, .406 ID x 1.0 OD x .105 1
14 01000897 Screw, TT, 1/4-20, 1.0, Hex Index Washer 1
15 01002751 Spacer, .39 x .63 x 1.75 1
16 01002771 Cotter Pin, .072 x 1.12 Lg 6
17 01003595 Brake Handle 1
18 01003468 Spacer, .375 x .50 x .75 Lg 1
19 01003574 Neutral Brake Spring 2
20 01003575 Force Brake Spring 2
21 01003716 Parking Brake Grip 1
22 01008600 Socket Head Capscrew, 5/16-18 x 1.50 1
23 01008607 Spacer, Pump Release 1
24 01008886 Brake Rod 1
25 01008889 Parking Brake Mounting Bracket 1
26 01009561 Brake Arm Assembly 1
27 01009566 Brake Arm Bracket 2
28 01009569 Pivot Brake Shaft 1
29 01009601 Hose, .5 ID x .78 OD, Low Pressure 2
30 01009602 Spacer, .76 ID x 1.0 OD x 3/4 2
31 02000015 Connector Rod Rod 2
