23HP Kawasaki Engine Assembly - Parts List for Figure 12
Ref
No Part No.
Description
Qty.
1
00005763 Hex Nut, 7/16-14
1
2
00006129 HHCS, 5/16-18, 1-3/4
4
3
01000811 Screw, #8-32 x 0.375
2
4
00014602 Round Hd. Machine Screw, 10-32 x 3/4
2
5
00014608 Lock Nut, Nylon Insert, 10-32
2
6
01005856 Key, 1/4 x 1/4 x 3
1
7
00022560 Flange Lock, Hex Nut, 3/8-16
2
8
00060056 Nut Washer, W/Star, 8-32
2
9
00060078 Grease Fitting, 1/4-28 x 3/16
1
10
01009635
Extension Spring, .98 OD x 5.00
1
11 01000302 Shoulder Screw, 7/16-14
1
12 01000364 Hex Carriage Screw, 3/8-16, 1.75
1
13 01000389 Lock Washer, 7/16
2
14 01000635 Hexflange Lock Nut, 5/16-18
4
15 01000721 Machine Screw, 8-32, .375
2
16 01000728 Clip, Heat Shield Cable
1
17 01001395 Capscrew, 7/16-20 x 2.50
1
18 01001979 Clutch Brake, 1.125 ID
1
19 01002601 Hex Cap Screw, 3/8-16, .750
1
20 01006456 Retainer Clutch Assembly, Ogura
1
21 01003269 Flat Washer, 7/16 ID x 1.75 OD x .25
1
22 01003271 Choke, Control Cable, 43.0
1
23 02000645 Throttle, Control Cable, 39.0
1
24 01003283 Oil Drain Hose
1
25
01008523
23HP Engine, Kawasaki
1
26 01004004 Control Throttle Knob
2
27 01004081 Flat Pulley with Flanges
1
28 01009299 Muffler Accessory, Kawasaki
1
29 01005006 Engine Idler Arm Assembly Includes
1
01000308 Bearing
2
30
02000068
V Belt, A Section x .48.5
1
31 01008623 Muffler Accessory Exhaust Tube
1
32 01005104 Pump Drive Pulley
1
33 01005314 Flat Washer, 7/16 ID x 1.75 OD x .25
1
34 00012169 Flat Washer, .320 ID x .591 OD x .078
1
Note: Engine Oil 10w40
