Cavity Cartridge
Fuse
Mini
Fuse
Description
10 20 Amp
Yellow CCN Power Locks
11 15 Amp
Lt Blue Power Outlet
12 20 Amp
Yellow Ign Run/Acc Inverter
13 20 Amp
Yellow Pwr run/Acc Outlet
RR
14 10 Amp
Red IOD CCN/ Interior
Lighting
15 40 Amp
Green RAD Fan Relay Bat-
tery Feed
16 15 Amp
Lt. Blue IGN Run/Acc Cigar
Ltr/Sunroof
17 10 Amp
Red IOD Feed Mod-Wcm
18 40 Amp
Green ASD Relay Contact
PWR Feed
19 20 Amp
Yellow PWR Amp 1 & Amp
2 Feed
Cavity Cartridge
Fuse
Mini
Fuse
Description
20 15 Amp
Lt. Blue IOD Feed Radio
21 10 Amp
Red IOD Feed Intrus
Mod/Siren
22 10 Amp
Red IGN RUN HVAC/
Compass Sensor
23 15 Amp
Lt. Blue ENG ASD Relay Feed
3
24 25 Amp
Natural PWR Sunroof Feed
25 10 Amp
Red Heated Mirror
26 15 Amp
Lt. Blue ENG ASD Relay Feed
2
27 10 Amp
Red IGN RUN Only ORC
Feed
28 10 Amp
Red IGN RUN ORC/OCM
Feed
29 Hot Car (No Fuse Re-
quired)
