Char-Broil 463230511 User Manual
Page 18
3
•
Hook tank exclusion wire onto the metal taps on lower back panel, attach other ends to bottom shelf with #8-32x3/8” sheet metal
screws.
4
•
Attach to left and right side panels with
flange nuts.
Place front door brace as shown.
1/4"-20x2-3/8" machine screws and 1/4”-20
Sheet Metal Screws
Qty. 2
#8-32x3/8"
Front Door Brace
1/4 -20
Flange Nut
"
Qty. 4
1/4 -20x2-3/8"
Machine Screw
"
Qty. 4
Metal Tap
Lower Back Panel
18
