DETAIL A
1
1
2
2
3
3
4
4
A A
B B
A
976 Hartford Turnpike
Waterford, CT 06385 USA
(800)243−0533 Fax: (800)988−3363
www.jaypro.com
DATE: DRAWN BY:
2/9/2012
MODEL NUMBER: CHECKED BY:
PRODUCT NAME:
DRL
FIELD
FBGP-620 SERIES
WVB
REV:
A
FIGURE 1
NOTE:
1)FRONT EDGE OF GOAL POST CROSSBAR IS TO LINE UP WITH
INSIDE EDGE OF ENDLINE.
2) CENTER OF GOOSENECK UPRIGHT IS TO BE 62 1/4"
FROM INSIDE EDGE OF ENDLINE.
360'-0"
(INSIDE EDGE OF GOAL POST TO
INSIDE EDGE OF GOAL POST)
GOAL POST
(GOOSENECK
TYP 2)
T:\Aftermarket\Football\FOOTBALL GOAL POST 600\620 DWGS\FIELD.idw
62 1/4 in
(FBGP-620)
CENTER OF
GOOSENECK
UPRIGHT
INSIDE EDGE OF
ENDZONE (SEE NOTE)
REV DESCRIPTION DATE BY
A DISTANCE BETWEEN UPRIGHT AND CROSSBAR WAS 55 in 2/9/2012 DRL
