opposing wedges at either end are drawn in tightly providing full length, 360° expansion over a large
bearing area. For maximum expansion, the upper cone should protrude slightly before setting.

1. Drill hole of recommended diameter (⅞” for a ½” bolt) into the base material to a depth equal

to, or slightly deeper than the length of the expansion anchor. Clean out the hole of all dust and
cuttings.

2. Place the Double Expansion anchor, nut end first, into the hole. The top end of the anchor

should be flush or slightly below the base material surface.

3. Place the object to be fastened over the anchor in the base material and bolt in to place.

Installer Note: Only ½” bolts are recommended for use by Jaypro. For availability, please contact
Jaypro Sports New Construction Customer Service.

Appendix B – Equipment Maintenance

MAINTENANCE INSTRUCTIONS

Jaypro prides itself on manufacturing high quality, durable and safe equipment. It is very
important however that certain maintenance be performed annually on all our basketball
backstops to insure years of safe, trouble-free use. This work must be completed by a qualified
installer or technician. If one is not available to you, Jaypro’s own field service team can be hired
to do the work. See number below, as for a field service manager to schedule an on-site visit.

BEFORE THE START OF EVERY SEASON, YOU MUST:

♦ Visually inspect entire unit to make sure that no parts have slipped or moved. (NOTE: To do

this quickly, look to see if any unpainted areas have become visible or if painted areas have
become damaged.)

♦ Check backboard for level and plumb. (NOTE: If backboard is not plumb, it is necessary to

adjust brace for plumb.)

♦ Check goal for appropriate height and level.

♦ Inspect and tighten ALL nuts and bolts.

IF ANY PARTS ARE REQUIRED, PLEASE CALL JAYPRO DIRECT.

1-800-243-0533

Jaypro Part Number

HM6212
