mAI085-MB Actuator Interface Technical Manual /32
Distributive Intelligence
 CMC INDUSTRIAL ELECTRONICS LTD
7 mAI085-MB output 4, 0 = output off
8 in open mode, 1 = yes
9 setpoints all cleared, 1 = yes
10 local keyboard disabled, 1 = yes
11 always 0
12 RAM fault, 1 = yes
13 mAI085-MB parameter corruption, 1 = yes
14 mAI085-MB firmware fault, 1 = yes
15 mAI085-MB in calibration, 1 = yes
There are 4 command bits to control the interface. These command bits are active only on the
0 to 1 transition. The bit must be returned to 0 before the command will execute again. Each
of the bits acts independently. The mAI085-MB command register bit assignments are:
Bit Function
0 mAI085-MB to close mode, 1 = yes
1 mAI085-MB to open mode, 1 = yes
2 mAI085-MB, clear all setpoints, 1 = yes
3 mAI085-MB disable local keyboard, 1 = yes
4 mAI085-MB enable local keyboard, 1 = yes
5 not used, always write 0
6 not used, always write 0
7 not used, always write 0
8 not used, always write 0
9 not used, always write 0
10 not used, always write 0
11 not used, always write 0
12 not used, always write 0
13 not used, always write 0
14 not used, always write 0
15 not used, always write 0
