Lighting Systems
EG1-4
Page 5 of 5
Ballast and Lamp Ordering Combinations
Energos 1-Light T5 per 4' (121.92cm) (Nominal) Louver
Desgn.
Lamp Type
(T8 or T5)
Ballast
Factor (BF)
Ballast
THD (%)
Lamp
Rated
Wattage
Lamp
Rated
Output
Lamp
Color
(Kelvin)
IES Output
(Lumens)
System
Input
Watts
System
Efficiency
(lum/watt)
System
Lamp Life
(Hours)
Start Type
FM
T5
1
<10
28
2600
830
2600
31.0
83.9
20000
Program
FN
T5
1
<10
28
2600
835
2600
31.0
83.9
20000
Program
FO
T5
1
<10
28
2600
841
2600
31.0
83.9
20000
Program
GP
HO
1
<10
54
4450
830
4450
58.5
76.1
20000
Program
GO
HO
1
<10
54
4450
835
4450
58.5
76.1
20000
Program
GR
HO
1
<10
54
4450
841
4450
58.5
76.1
20000
Program
IM
T5DIM
1.0/.01
<10
28
2600
830
2600 /26
33.5/8
77.6
NA
Program
IN
T5DIM
1.0/.01
<10
28
2600
835
2600 /26
33.5/8
77.6
NA
Program
10
T5DIM
1.0/.01
<10
28
2600
841
2600 /26
33.5/8
77.6
NA
Program
JP
T5H0 DIM
1.0/.03
<10
54
4450
830
4450 /134
63 /12.5
70.6
NA
Program
JO
T5H0 DIM
1.0/.03
<10
54
4450
835
4450 /134
63 /12.5
70.6
NA
Program
JR
T5H0 DIM
1.0/.03
<10
54
4450
841
4450 /134
63 /12.5
70.6
NA
Program
Notes:
*25°C Rating
All data is per 1 lamp on a two lamp system at 277 VAC. Data is based on Osram Sylvania Specifications
When ordering no lamps provided by Lightolier, use Lamp code "Z".
The lumen value for the lamp (within a Lighting Design program) will be
the lES Output value shown on this table.
Job Information
Type:
631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710
We reserve the right to change details of design, materials and finish.
