Philips 151423 - Manual

4 3 / 4 "
◗ Ordering Information
Ordering Code CDM70/PAR30L/M/SP/4K
ANSI Designation M139/O
Product Number 151423
Description MasterColor
Ceramic Metal Halide
Package Quantity 6
◗ Physical Characteristics
Bulb Size PAR-30L
Bulb Finish Clear
Base Medium Screw
Max. Overall Length (MOL) 4 3/4" (121mm)
Light Center Length (LCL) N/A
Arc Length N/A
Arc Tube Material Polycrystalline Alumina
Max. Permissible Bulb Temp. 300º C (572º F)
Max. Permissible Base Temp. 190º C (374º F)
Max. Lens-to-Reflector Rim Temp. 160º C (320º F)
Max. Bulb to Base Eccentricity 3º
Max. Arc Tube to Base Eccentricity 3º
◗ Operating Characteristics (Photometric)
Rated Initial Lumens 1 4300
Mean Lumens, Approx. 2 3010
MBCP (Max. Beam Candlepower) 63,000
Beam Angle (at 50% of MBCP) 10º
Rated Average Life, Hours 3 9000
Correlated Color Temp. (CCT) 4 4000K
CIE Chromaticity Approx. 4 x-.371, y-.366
Color Rendering Index (CRI) 94
Efficacy (lpw) 61
◗ Operating Position
Universal-Open or Enclosed PAR Style Luminaires
Note: Operate only on thermally protected electronic ballasts.
MasterColor ® Ceramic Metal Halide
70 Watt PAR30L Spot 4K Lamp
with FadeBlock ™
