OPERATION RADIO RECEPTION
POWER on/off button ®
The set is switched on ^ and off ж. with POWER
button The POWER indicator wili light up when
the set is switched on.
MODE selector©
The desired sound source for reproduction or
recording is selected using MODE selector ®.
• Position RADIO for:
- radio reception
- radio recording on deck В
• Position TAPE (cassette) for:
- cassette playback on deck A or deck В (or both)
- COPY A>B: copying (’dubbing’) from deck A to
deck В
- CONTINUOUS AH-B ’continuous play AH’: play­
back of deck A, at the end of the cassette
automatically followed by playback of deck В
• Position CD/LINE IN for:
- listening to the signal from the CD/LINE IN
sockets @
- recording the signal from the CD/LINE IN
sockets ®
• Position MIC (microphone) for:
- mono recording on deck В from the microphone
MIC ® (set VOLUME control ® to zero)
Important: In order to avoid undesired mixing of
signals during recording and playback, the CD/
LINE IN sockets ® should be disconnected when
not in use.
Sound adjustment
The sound reproduced by the loudspeakers or by
stereo headphones can be adjusted by means of
the controls VOLUME ®, FM MONO/STEREO ®
and GRAPHIC EQUALIZER ®.
• The VOLUME control ® enables adjustment of
the sound volume.
• The GRAPHIC EQUALIZER® consists of sever­
al tone controls, each controlling its own pitch
range. The five equalizer controls are centered on
100 Hz (lower bass), 300 H 5 (upper bass), 1 kHz
(1 000 Hz, mid-range), 4 kHz (4 000 Hz, lower tre­
ble) and 10 kHz (10 000 Hz, upper treble).
• The FM MONO/STEREO selector ® is only
operative during FM stereo radio reception. In
position FM MONO, you will hear (and record) the
FM stereo programme in mono.
• Set the MODE selector © to RADIO.
• Select the wave band using BAND selector ©.
• Adjust the sound with the controls VOLUME @
and GRAPHIC EQUALIZER ®.
• Tune to a radio station using TUNING knob ®.
(LW and SW not on all versions)
- For FM-reception, pull out the telescopic aerial.
To improve FM-reception, incline and turn the
aerial. Reduce its length if the FM-signal is too
strong (very close to a transmitter).
- For AM/MW and LW reception (Medium and
Long Wave), the set is provided with a built-in
ferrite aerial, so there is no need to use the
telescopic aerial. The ferrite aerial can be direc­
ted by turning the whole set.
- For Short Wave (SW) reception, the telescopic
aerial must be pulled out and placed in the
vertical position. To improve SW-reception, vary
the length of the aerial.
• When FM MONO/STEREO selector ® is in
position STEREO and the FM STEREO indicator©
lights up, you are receiving a FM-stereo transmitter.
A disturbing noise, due to a weak FM-stereo signal,
can be suppressed by setting the FM MONO/STE­
REO selector ® to MONO. The FM STEREO
indicator ® will then go out and you will hear (and
record) the FM programme in mono.
CASSETTE RECORDER___________
Compact cassettes
For recording, always use NORMAL or FERRO
cassettes (ferric oxide, lEC type I).
For playback, any cassette type can be inserted.
Copyright
Recording is permissible insofar as copyright or
other rights of third parties are not infringed.
For U.K. on/yr Recording and Playback of material may require
consent See Copyright Act 1956 and The Perforfner's Protoctton
Acts 1958 to 1972.
Fast winding and rewinding
Press fast forward wind F.FWD ►► or REWIND 44
button. To stop fast winding, press STOP button ■.
End of the cassette
When the end of the tape is reached during
recording, playback and fast forward winding or
rewinding, the pressed recorder buttons will auto­
matically be released.
