Interlogix SuperBus 2000 2X20 User Manual
Product summary, Installation guidelines

SuperBus 2000 2X20 LCD Alphanumeric
Touchpad Installation Instructions
Product Summary
The SuperBus 2000
®
2 x 20 LCD (liquid crystal display)
Alphanumeric Touchpad gives you complete on-site system
programming and operation control of a compatible security
system (see the section “Specifications”).
A two-line, 40-character display provides visual system status
messages. The display identifies any programmed location,
allowing the user to determine where an alarm, trouble, or
open-sensor condition exists.
Other features include:
•
Touchpad buttons that light up after the first button press
and remain lit until about 15 seconds after the last button
press.
•
Adjustable display contrast and backlighting.
•
Built-in hardwire input (can be supervised with EOL
resistor in SuperBus 2000 panels).
•
Built-in door, which covers right-side buttons (60-809
only).
SuperBus 2000 Panels vs. SuperBus Panels
SuperBus 2000 panels assign module unit numbers
automatically when the panel is powered up. This eliminates
manually setting unit numbers and the chance of identical unit
number conflicts.
SuperBus 2000 Panels
• Advent
•
Concord (software versions 2.0 and newer)
• Concord
Express
• Concord
Ultra
SuperBus panels communicate with SuperBus 2000 modules
but require the module unit number to be set manually.
Touchpads automatically default to unit number 001.
SuperBus Panels
• UltraGard
•
Concord (software versions 1.0–1.6)
Installation Guidelines
•
For the maximum number of bus devices and touchpads
per panel (see Table 1 below).
Table 1: Maximum Bus devices per panel
Panel Maximum
Bus
Devices
Advent 62
Ultragard 8
Concord/Concord Express v4
16
Concord Express
4
•
Do not exceed the total panel output power when using
panel power for bus devices, touchpads, and hardwired
sensors that require it (see specific panel Installation
Instructions).
•
Maximum current draw from the touchpad is 120 mA.
•
Minimum current draw from the touchpad when the panel
is operating only on backup battery is 15 mA.
•
Mount the touchpad in an environmentally controlled area
(32° to 140° F) (0° to 60° C).
•
When using the optional touchpad hardwire input, use only
shielded wire (22-gauge or larger), and do not exceed the
maximum wire length limits in Table 2 below between the
touchpad and detection device.
Note: Shield wire must be connected to earth ground
Table 2: Hardwire input wire length limits
Gauge Max.
wire
length
18 (shielded)
1000 feet
22 (shielded)
350 feet
•
When mounting the touchpad back-plate, allow a 1-inch
clearance on all sides since the touchpad is larger than
the back-plate.
•
Use 4-conductor, 22-gauge or larger stranded wire from
the touchpad to the control panel.
P/N 466-1632 • REV D • 07APR11
1
