NX-1700E Card Reader
15
LOC
PG
DESCRIPTION
DEFAULT
YOUR DATA
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
265
OPENING TIME FOR SCHEDULE 7
Seg 1
Hour of Opening Time (24-hr format)
8 = 8 AM
Seg 2
Minutes after Hour of Opening
0
266
CLOSING TIME FOR SCHEDULE 7
Seg 1
Hour of Closing Time (24-hr format)
20 = 8 PM
Seg 2
Minutes after Hour of Closing
0
267
DAYS FOR SCHEDULE 7
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
268
OPENING TIME FOR SCHEDULE 8
Seg 1
Hour of Opening Time (24-hr format)
8 = 8 AM
Seg 2
Minutes after Hour of Opening
0
269
CLOSING TIME FOR SCHEDULE 8
Seg 1
Hour of Closing Time (24-hr format)
20 = 8 PM
Seg 2
Minutes after Hour of Closing
0
270
DAYS FOR SCHEDULE 8
1 = "On" if schedule is active on Sunday.
2 = "On" if schedule is active on Monday.
3 = "On" if schedule is active on Tuesday.
4 = "On" if schedule is active on Wednesday.
5 = “On” if schedule is active on Thursday.
6 = “On” if schedule is active on Friday.
7 = “On” if schedule is active on Saturday.
8 = “On” if schedule is disabled on holidays.
271
HOLIDAYS IN JANUARY (8 max)
No holidays
_ _ _ _ _ _ _ _
HOLIDAYS IN FEBRUARY (8 max)
No holidays
_ _ _ _ _ _ _ _
272
273
HOLIDAYS IN MARCH (8 max)
No holidays
_ _ _ _ _ _ _ _
274
HOLIDAYS IN APRIL (8 max)
No holidays
_ _ _ _ _ _ _ _
275
HOLIDAYS IN MAY (8 max)
No holidays
_ _ _ _ _ _ _ _
276
HOLIDAYS IN JUNE (8 max)
No holidays
_ _ _ _ _ _ _ _
277
HOLIDAYS IN JULY (8 max)
No holidays
_ _ _ _ _ _ _ _
278
HOLIDAYS IN AUGUST (8 max)
No holidays
_ _ _ _ _ _ _ _
279
HOLIDAYS IN SEPTEMBER (8 max)
No holidays
_ _ _ _ _ _ _ _
280
HOLIDAYS IN OCTOBER (8 max)
No holidays
_ _ _ _ _ _ _ _
281
HOLIDAYS IN NOVEMBER (8 max)
No holidays
_ _ _ _ _ _ _ _
282
HOLIDAYS IN DECEMBER (8 max)
No holidays
_ _ _ _ _ _ _ _
283
ACTIVATION DATA FOR USER CARDS 1 - 120
1 = User Cards 1 – 8
2 = User Cards 9 – 16
3 = User Cards 17 – 24
4 = User Cards 25 – 32
5 = User Cards 33 – 40
6 = User Cards 41 – 48
7 = User Cards 49 – 56
8 = User Cards 57 – 64
9 = User Cards 65 – 72
10 = User Cards 73 – 80
11 = User Cards 81 – 88
12 = User Cards 89 – 96
13 = User Cards 97 – 104
14 = User Cards 105 – 112
15 = User Cards 113 - 120
284
LED1 = Card 1
LED2 = Card 2
LED3 = Card 3
LED4 = Card 4
LED5 = Card 5
LED6 = Card 6
LED7 = Card 7
LED8 = Card 8
ACTIVATION DATA FOR USER CARDS 121 - 240
9 = User Cards 185 – 192
1 = User Cards 121 – 128
10 = User Cards 193 – 200
2 = User Cards 129 – 136
11 = User Cards 201 – 208
3 = User Cards 137 – 144
12 = User Cards 209 – 216
13 = User Cards 217 – 224
14 = User Cards 225 – 232
15 = User Cards 233 – 240
4 = User Cards 145 – 152
5 = User Cards 153 – 160
6 = User Cards 161 – 168
7 = User Cards 169 – 176
8 = User Cards 177 – 184
