3BChapter 4: Configuring the camera
Figure 16: Video setting menu
Parameter Description
Channel name Name of the camera
Encoding parameters Specifies the dual streaming method used.
Options include: Main stream and sub stream. Default is Main.
Stream type Specifies the stream type you wish to record.
Select Video to record video stream only. Select Video&Audio to record
both video and audio streams. Default value is Video&Audio.
Resolution Specifies the recording resolution. A higher image resolution provides a
higher image quality but also requires a higher bit rate. The resolution
options listed depend on the type of camera and on whether main or
sub stream is being used. If you make changes to this option, you must
reboot the camera to implement the changes. The options are:
Main stream: 352*240, 352 *288, 640*480, 704*480, 704*576, 800*600,
1280*720, 1280*960, 1600*1200, 1600*912, 1920 *1080, 2048*1536
and 2560*1920
Sub stream: 176*144, 320*240 and 352*240
Note : Resolutions can vary depending on the camera model.
Image quality Specifies the quality level of the image.
Value is prepopulated High. It cannot be changed.
Bit rate type Specifies whether variable or fixed bit rate is used. Variable produces
higher quality results suitable for video downloads and streaming.
Default is Variable.
Max bit rate Specifies the maximum allowed bit rate. A high image resolution
requires that a high bit rate must also be selected.
Options include: 32 bps, 48, 64, 80, 96, 128, 160, 192, 224, 256, 320,
384, 448, 512, 640, 768, 896, 1024, 1536, 1792, 2048, Custom (enter a
value manually) Default is 2048.
TruVision IP Dome Open-Standards User Manual 33
