UltraView UVD-6130VE-2 WDR Dome Camera User Manual 11
Menu Item Description
ATW ATW (automatic tracing white balance) limits the color temperature range
between 2,500 to 8,500˚K to reduce excessive compensation for a large
single-color object. Use it to automatically adjust the WB in real time as
the lighting conditions change. It can be used for both indoor and outdoor
locations.
Set the following options:
Speed: Set the compensation speed between 0 and 255. A lower value
makes the AWB faster.
Delay CNT: Set the delay time between automatic adjustments of the
AWB. A smaller value increases the frequency rate of AWB.
ATW Frame: X0.5, X1.0, X1.5, X2.0. Default is X2.0.
Environment: Select Indoor (ATW is compensated for low color
temperature such as from incandescent lighting) or Outdoor (ATW is
compensated for high color temperature such as from daylight). Default is
Indoor.
Push Like ATW, the Push function continually monitors/analyzes the color
temperature of the incoming light and corrects the WB. However, Push
has no limits between 1,800 to 10,500˚K so it may over-compensate the
WB for a large single-color object.
User1 This is a fixed white balance that is user-defined by blue and red gain
parameters. Only use this function when there is steady light.
Blue-gain from 0 to 255
Red- gain from 0 to 255
User2 This is a second fixed white balance that is user-defined by blue and red
gain parameters. Only use this function when there is steady light.
Blue-gain from 0 to 255
Red- gain from 0 to 255
Anti CR The anti-color rolling mode function minimizes the color changes over
long periods caused by very small differences between the flicker
frequency of non-inverter fluorescent lights and the drive frequency of the
image sensor devices.
Manual Manually adjust the white balance by blue gain only. The red gain is
automatically adjusted when the blue gain is changed. Only use this
function when there is steady light.
Level UP: Press Enter to increase the WB level.
Level DOWN: Press Enter to decrease the WB level.
Push Lock Press Enter to automatically adjust the white balance to the environment
and lock it at this value.
Set WDR
Wide dynamic range (WDR) allows you to see details of objects in shadows or
details of objects in bright areas of frames that have high contrast between light
and dark areas such as the headlights of a passing car.
In the Setup menu, go to WDR and select the options to be modified in the menu.
