16 TruVision TVC-6110-1 / TVC-6120-1 Camera User Manual
Specifications
Model TVC-6110-1-N(P) TVC-6120-1-N(P)
Pickup device 1/3" Super HAD CCD II
Total pixels NTSC: 811 × 508 / PAL: 795 × 596
Effective pixels NTSC: 768 × 494 / PAL: 752 × 582
Resolution 600 TVL
Synchronization system Internal Internal / Line up
Scanning system 2:1interlace
IR cut NA Yes
S/N ratio 52 dB (AGC Off)
Electronic shutter PAL: 1/50 to 1/10,000 s
NTSC: 1/60 to 1/10,000 s
Minimum illumination 0.01 lux (F1.2, AGC X1)
Video output 1 Vpp composite output (75 ohm/BNC)
White balance ATW/ PUSH/ USER1/ USER2/ ANTI CR/ MANUAL/
PUSH LOCK
Lens type C/CS-DC
Power supply 12 VDC 24 VAC / 12 VDC
Current 160 mA 330mA
Power consumption Max. 2.0 W Max. 4.0 W
Operating temperature -10 to +50 °C (14 to 122 °F)
Weight 400 g (0.88 lbs)
Dimensions
(Units of measurement = mm)
