IFS POE302-SP Ethernet Splitter User Manual 3
Product Overview
Figure 1 shows the front and side panels of the POE302-SP.
Figure 1: POE302-SP Front and Side Panels
LED Indicator
POE302-SP LED indicator
LED
Color
Function
PoE In
Green
Steady on indicates the unit is receiving 56VDC
PoE in-line power.
Hardware Installation
The POE302-SP operates at three different data rates -
10Mbps, 100Mbps and 1000Mbps. The unit adjusts
automatically to the incoming data rate.
The following section describes the hardware features of the
POE302-SP. Carefully read this section before connecting any
network device to this unit.
