IFS POE302-SP Ethernet Splitter User Manual 7
Specifications
POE302-SP Specifications
Product POE302-SP
Hardware Specification
“Data” Out Port 1 x RJ-45 STP
“PoE (Power +
Data)” Input Port
1 x RJ-45 STP
Interface
DC Out Plug
Connector
1
LED Indicator System: PoE In x 1 (Green)
Network Cable 10Base-T: 2-Pair UTP Cat. 3, 4, 5, up to 100m (328ft)
100Base-TX: 2-Pair UTP Ca5, 5e, & 6 up to 100m
(328ft)
1000Base-T: 2-Pair UTP Cat. 5, 5e, 6 up to 100m
(328ft)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate 10/100/1000Mbps (vary on Ethernet device attached)
DIP Switch 12V DC / 24V DC output voltage
Dimension (W x D x H) 3.75 X 2.75 X 1.0 in (95 X 70 X25 mm)
Weight .25 lbs (111g)
Number of device can be
powered 1
Operating Temperature 0 ~ 50 Degree C
Storage Temperature -10 ~ 70 Degree C
Humidity 5 ~ 90% (Non-condensing)
Power over Ethernet
PoE Standard IEEE 802.3at High Power over Ethernet / PD
Standards Conformance
Standards Compliance IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
IEEE 802.3ab 1000Base-T Gigabit Ethernet
IEEE 802.3at Power over Ethernet
Regulation Compliance FCC Part 15 Class A, CE
