- 17 -
A.3 Fiber-Optic Cable Connection Parameter
The wiring details are as below:
Cables:
Standard Fiber Type Cable Specification
1000Base‐SX(850nm) Multi‐mode 50/125μm or 62.5/125μm
Multi‐mode 50/125μm or 62.5/125μm 1000Base‐LX(1300nm)
Single‐mode 9/125μm
Wiring Distances:
Standard Fiber Diameter (micron) Modal Bandwidth (MHz *
km)
Max. Distance (meters)
1000Base‐SX MM 62.5
62.5
50
50 100
200
400
500 220
275
500
550
MM 62.5
50
50 5
4
5 550
1000Base‐LX
SM 9 N/A 5000*
