- 12 -
„ Approved IFS SFP Transceivers
The MCR300-1T-2S Gigabit Media Converter supports both Single mode and Multi-mode SFP transceiver. The following list of
approved IFS SFP transceivers is correct at the time of publication:
UTC Model SFP Description
S30-1SLC/A-10 SFP, LC Connector, Single Mode, Gigabit, 1 fiber, 1310nm/1550nm, 10km , A End
S30-1SLC/A-20 SFP, LC Connector, Single Mode, Gigabit, 1 fiber, 1310nm/1550nm, 20km, A End
S30-1SLC/A-60 SFP, LC Connector, Single Mode, Gigabit, 1 fiber, 1310nm/1550nm, 60km, A End
S30-1SLC/B-10 SFP, LC Connector, Single Mode, Gigabit, 1 fiber, 1550nm/1310nm, 10km , B End
S30-1SLC/B-20 SFP, LC Connector, Single Mode, Gigabit, 1 fiber, 1550nm/1310nm, 20km, B End
S30-1SLC/B-60 SFP, LC Connector, Single Mode, Gigabit, 1 fiber, 1550nm/1310nm, 60km, B End
S30-2MLC SFP, LC Connector, Multi Mode, Gigabit, 2 fiber,850nm/850nm, 550m
S30-2MLC-2 SFP, LC Connector, Multi Mode, Gigabit, 2 fiber,1310nm/1310nm, 2km
S30-2SLC-10 SFP, LC Connector, Single Mode, Gigabit, 2 fiber,1310nm/1310nm, 10km
S30-2SLC-30 SFP, LC Connector, Single Mode, Gigabit, 2 fiber,1310nm/1310nm, 30km
S30-2SLC-70 SFP, LC Connector, Single Mode, Gigabit, 2 fiber,1550nm/1550nm, 70km
S30-RJ SFP, RJ-45, Gigabit, 100m
2.5.2 Media Chassis Installation
To install the Gigabit Media Converter in a 19-inch width standard rack, follow the instructions described below.
Step 1 : Place your Gigabit Media Converter on a hard flat surface, with the front panel positioned towards your front side.
Step 2 : Carefully slide in the module until it is fully and firmly fitted into the slot of the chassis, the Power LED of the Gigabit Media
Converter will turns ON.
Figure 2-5-2: Insert a Gigabit Media Converter into an available slot
