Installation Steps
Step 1: Unpack the Industrial Gigabit PoE+ Switch.
Step 2: Check the DIN-Rail is screwed on the Industrial Gigabit PoE+ Switch. (Please refer to DIN-Rail
Mounting section for DIN-Rail installation, if the DIN-Rail is not screwed on the Industrial switch).
If you want to wall-mount the Industrial Gigabit Ethernet Switch, please refer to Wall Mount Plate
Mounting section for wall-mount plate installation.
Step 3: To hang the Industrial Gigabit PoE+ Switch on the DIN-Rail track or wall, please refer to the
Mounting Installation section.
Step 4: Power on the Industrial Gigabit PoE+ Switch. (Please refer to the Wiring of the Power Inputs
section for power input) The power LED on the Industrial Gigabit PoE+ Switch will light up.
Please refer to the LED Indicators section for the functions of LED lights.
Step 5: Prepare the twisted-pair, straight through Category 5 cable for Ethernet connection.
Step 6: Insert one side of Category 5 cable into the Industrial Gigabit PoE+ Switch Ethernet port (RJ-45
port) and the other side of category 5 cable to the network devices' Ethernet port (RJ-45 port), eg.
switch, PC or Server. The UTP port (RJ-45) LED on the Industrial Gigabit PoE+ Switch will light
up when the cable is connected with the network device. Please refer to the LED Indicators
section for the functions of LED lights.
Step 7: When all connections are set and all LED lights show normally, the installation is complete.
Be sure the connected network devices support MDI/MDI-X. If it does not support, then
use the crossover category 5 Cable.
