22 IFS MC251-4P/1CXT User Manual
Specifications
Product MC251-4P/1CXT
Hardware Specification
10/100 Base-TX 4 x RJ-45, Auto-Negotiation and Auto-MDI/MDI-X
PoE 4 x PoE (Port1 ~ Port4)
Ports
VDSL
1 x RJ-11, female Phone Jack
1 x BNC, female connector
DIP Switch 4 position DIP switch
Functionality*1
Master / Slave mode select
Selectable BNC and RJ-11 mode
Selectable target Band Plan
Selectable target SNR mode
Encoding
VDSL-DMT
- ITU-T G.997.1
- ITU-T G.993.1 VDSL
- ITU-T G.993.2 VDSL2 (Profile 17a Support)
LED Indicators
P1 (Green)
P2 (Green)
Fault (Green)
Master (Green) and Slave (Green)
ACT (Green)
Sync. (Green)
PoE ( Orange)
PoE Standard IEEE 802.3af Power over Ethernet / PSE
PoE Type End-Span
PoE Power Input 24V or 48V DC power input source
PoE Power Output 48V DC Per Port, 350mA . Max. 15.4 Watts
Power Over
Ethernet
PoE Pin
Assignment
1/2(+), 3/6(-)
Ethernet
 10Base-T: 2-pair UTP Cat.3,4,5 up to 100m (328ft)
 100Base-TX: 2-pair UTP Cat.5, 5e, 6 up to 100m (328ft)
VDSL(RJ-11) Twisted-pair telephone wires (AWG24 or better) up to 1.4km Cabling
BNC 50 ohm: RG58A/U, RG58C/U, RG58/U and 75 ohm: RG6 (Distance 2.4km)
Asymmetric Mode
VDSL (RJ-11) BNC
