8. Trip the desired transmitter (within 250 seconds) as
described in
. Listen for the ding dong for
confirmation
.
Note
: For specific instructions on tripping a transmitter,
consult the transmitter’s manual
Table 4. Tripping transmitters
Transmitter Action
Door/window, shock,
glass guard, freeze,
UFT (Universal Fire
Transmitter)
Activate tamper switch by removing cover.
Door/window with
external contact
Activate tamper switch by removing cover.
Feature 4—Input option 1, must be on.
Recessed
door/window
Activate tamper switch by removing circuit
board until tamper switch is exposed.
Micro door/window
and Micro recessed
door/window
Refer to the installation instructions for the
specific sensor for activation information.
SlimLine door/window Remove cover, then press the button on the
top of the sensor, or activate the tamper
switch by removing the cover.
PIR
Activate tamper switch by removing back
plate from PIR.
Smoke detector
without tamper switch
Press and hold the test button.
Smoke detector with
tamper switch
Trip the tamper switch. Feature 4—Input
option 1, must be on.
Heat detector
Press, then release the tamper switch.
Single button panic
Press and hold the button.
Dual button panic
Press and hold both buttons together.
Keyfobs
Press and hold the lock and unlock buttons
together.
Repeater
Press, then release the tamper switch
9. To program remaining transmitters, repeat steps 6 to 8.
10. To exit program mode, press EXIT EXIT.
11. Confirm that the zone types and partition assignments are
set correctly in the control panel. Refer to the control panel
installation manual for instructions on how to set zone
types and partition assignments.
Note:
When an 80-bit device is added, Feature 6 of
Segment 1 (see
) is turned on. But when a 63-bit
device is added on a zone location that previously had an
80-bit device, make sure to turn off Feature 6 of Segment
1.
Transmitter options
LCD touchpads will display instructions when accomplishing
tasks.
To program the transmitter and partition settings, do the
following:
1. Enter * 8 at the keypad. On LED touchpads, the five
function lights start flashing.
2. Enter the program code (factory default is 9713). On LED
touchpads, the service light flashes and the five function
lights change from flashing to on steady.
3. Enter the DIP switch setting module number for the
receiver and press #. On LED touchpads, the Armed LED
turns on to indicate the control panel is waiting for a
programming location entry.
4. Enter the zone location number and press #. On LED
touchpads, the Armed LED turns on and the Zone LEDs
display the binary data for the current settings.
5. Press the keypad button that corresponds to the feature
number you want changed. On LED touchpads, the lights
corresponding to the feature number will turn on or off
depending on the previous state. On LCD touchpads, the
feature number will turn on or off depending on the
previous state.
6. Press * to enter the changes and automatically advance to
segment 2.
Note
: If you press # instead of * in step 6, it exits the zone
location and does not save changes to transmitter options.
7. Press # to exit zone location. To continue programming
other zone locations, repeat steps 4 to7. To exit program
mode, press EXIT EXIT.
Door/window transmitter settings
Use the following guidelines when setting features 4 and 5
(see Segment 1 in
) for door/window transmitters:
•
Feature 4 - Input option 1. Turn on this feature to disable
the transmitter’s internal reed switches.
•
Feature 5 - Input option 2. For transmitters that use a
normally open (N/O) external contact, leave this feature
off. For transmitters that use a normally closed (N/C)
external contact, turn this feature on.
Wireless smoke detector settings
Use the following guideline when setting feature 4 (see
Segment 1 in
) for wireless smoke detectors:
•
Feature 4 - Input option 1. For detectors with tamper
switches, turn on this feature to enable the tamper feature.
Note
: Feature 4 must be off (disabled) when using
wireless smoke detectors without tamper switches.
4-button keyfob settings
