194
Receiver zone bank
setting (default = 0),
set this before learning
any sensors.
Applies only to NX8E.
Starting zone
numbers by bank
setting:
0 = 1
1 = 9
2 = 17
3 = 25
4 = 33
5 = 41
6 = 49
7 = 57
8 = 65
9 = 73
10 = 81
11 = 89
12 = 97
13 = 105
14 = 113
15 = 121
16 = 129
17 = 137
18 = 145
19 = 153
20 = 161
21 = 169
22 = 177
23 = 185
Normal ______hours.
(0 to 255 hours;
default = 24 hours)
Fire ______hours.
(0 to 255 hours;
default = 4 hours)
195
Supervision Windows
Segment 3:
Short supervision time _____minutes (1 to 30
minutes, default = 40 minutes - disabled)
Do not change Segment 3 setting unless
required. See step 7 under Transmitter
supervision .
Supported devices
For 80-bit devices, Feature 6 must be on for Segment 1 on
zone location. For 63-bit devices, Feature 6 must be off for
Segment 1 on zone location.
80-bit devices
• 60-849-02-95 ESL Smoke Detector
• 60-917-95 Universal Fire Transmitter
• 60-832-95R 2 Button Keychain Touchpad *
63-bit devices
• NX-450 (60-670-95R) SAW Door/Window Sensor, White
• NX-451 (60-670-11-95R) SAW Door/Window Sensor, Brown
• NX-452 (60-499-10-319.5) SlimLine Door/Window Sensor,
White
• NX-453 (60-499-11-319.5) SlimLine Door/Window Sensor,
Brown
• NX-458 (60-751-95) Recessed Micro Door/Window
Sensor
• • 60-741-11-95 Recessed Micro Door/Window Sensor,
Brown
• NX-470 (60-659-95R) 4-Button Keychain Touchpad
• NX-474 (60-906-95) Micro Multi-Purpose Crystal Panic Button
• NX-475 (60-578-10-95) Water-Resistant Pendant Panic
Sensor
• NX-480 (60-639-95) Indoor SAW PIR Motion Sensor
• • 60-639-95R-OD Outdoor SAW PIR Motion
• • 60-639-02-95R SAW PIR Motion w/1.5v
• NX-487 (60-834-95) Adjustable Dual Technology Sound
Sensor
• NX-490 (60-506-319.5) Wireless Smoke Sensor
• NX-491NT (60-848-02-95) ESL 560 Series Wireless
Smoke Sensor
• NX-495 (60-460-319.5) Rate-of-Rise Heat Sensor
• NX-650 (60-362-10-319.5) Standard Door/Window
Sensor, White
• NX-651 (60-362-11-319.5) Standard Door/Window
Sensor, Brown
• NX-652 (60-641-95) Long Life Door/Window Sensor, White
• NX-653 (60-641-11-95) Long Life Door/Window Sensor,
Brown
• NX-454 (60-688-95) Micro Door/Window Sensor, White*
• NX-455 (60-688-11-95) Micro Door/Window Sensor, Brown*
• NX-481 (60-807-95R) Indoor SAW PIR Motion Sensor*
• NX-482 (60-880-95) AP750W PIR Motion Sensor*
• NX-488 (60-873-95) ShatterPro Crystal Glass Break Sensor*
• NX-497 (60-652-95) Crystal Carbon Monoxide Sensor*
• NX-656 (60-462-10-319.5) Glass Guard Crystal Sensor,
White*
• NX-657 (60-462-11-319.5) Glass Guard Crystal Sensor,
Brown *
• NX-658 (60-742-95R) Crystal Freeze Sensor*
• NX-667 (60-886-95) Crystal Learn Mode Shock Sensor,
White*
• NX-668 (60-886-11-95) Crystal Learn Mode Shock
Sensor, Brown*
• NX-695 (60-744-95R) SAW Water Sensor*
• NX-706 (80-922) Repeater Kit 319.5*
• NX-707 (80-922-1) Repeater Kit 319.5 *
NetworX NX-548-E Receiver Installation Instructions 11
