SECTION 6 — CUSTOM INFORMATION
6.1 UNIT IDENTIFICATION
Model no.:
Serial no.:
Customer identification:
6.2 CONFIGURATION
The marked (X) items denote the configuration of this unit as originally shipped from the
factory.
Pipe Connection: Hot tap with 1½" MNPT connection
Input Power: 100-250 Vac, 50/60 Hz
Outputs:
Analog: 8 outputs (4-20mA) for each probe
Digital: Ethernet
RS-232/RS-422
Data Access: Ethernet communication
Portable Data Storage: Portable USB Data Storage Device
Enclosures shipped: Cables Shipped:
Processor Box 5711 interconnect cable (RS485) -
Distribution Box Cat5 Ethernet cable - 10 ft
Transmitter Box RS232 communication - 20 ft
Software: Windows compatible RheoVac 950 system software, — Version 051509
User interface software on CD — Version 112008
Calibrated for customer line size of inches, schedule
6.3 SPECIAL INSTRUCTIONS
The next page shows a sketch of a typical layout for a Model 950 with all components located
near each other on the plant floor. Other configurations can be used, but there are rules as to
how an RS485 signal can be run, so if you are thinking of using some significantly different
arrangement for your installation, please contact the factory (614-895-0301) to review your
plans.
