2
Power
z External power adapter. Support DC 12V/AC 24V power supply.
PoE
z Support Power over Ethernet (PoE). Conform to the IEEE802.3af
standard.
z Connect the device to the switcher or the router that supports the
PoE function to realize the network power supply.
z To guarantee proper performance, please make sure the power
sourcing device can supply at least 10W power.
z Usually, do not use the PoE for the WIFI/3G device.
Assistant
Function
z Day/Night mode auto switch (ICR switch.)
z Backlight compensation: screen auto split to realize backlight
compensation to adjust the bright.
z Support system resource information and running status real-time
display. Support log function.
z Support video watermark function to avoid vicious video modification.
z Support auto aperture.
z Support picture parameter setup such as electronic shutter and gain
setup.
z Support dual-stream, ACF(Active frame control )
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for IPC performance specification.
Model
Parameter IPC-
HF3500
Series IPC-
HF3300
Series IPC-
HF3200
Series IPC-
HF3100
Series
IPC-HF3110
Series
Main
Processor TI Davinci high performance DSP
OS Embedded LINUX
System
Resources Support real-time network, local record, and remote operation at the
same time.
User Interface Remote operation interface such as WEB, DSS, PSS
System
System Status
SD card status, bit stream statistics, log, and software version.
Image Sensor
1/2.8-inch
CMOS 1/2.8-inch
CMOS 1/2.9-inch
CMOS 1/3-inch
CMOS
1/3-inch CCD
Pixel
2560(H)*19
20(V) 2080(H)*1
553(V) 1920(H)*1
200(V) 1280(H)*9
60(V) 1280(H)*960(V
)
Day/Night
Mode
Support day/night mode switch and IR-CUT at the same time.
Auto Aperture
Optional
Gain Control Fixed/Auto
White Balance
On/off
BLC On/off
Electronic
Shutter
Manual/Auto
PAL: It ranges from 1/3 to 1/10000.
NTSC: It ranges from 1/4 to 1/10000.
Manual/Auto
PAL: It ranges
from 1/3 to
1/100000.
NTSC: It
ranges from
1/3 to
1/100000.
Video Parameter
Video
Compression
Standard
H.264/JPEG/MJPEG
