2 framework, 1 rear panel – IC Realtime 2 MegaPixel Full HD IP Box Camara (ICIPS2000) User Manual
Page 19
13
2 Framework
2.1 Rear Panel
This series IP camera real panel is shown as below. See Figure 2-1.
The rear panel with the network port
The rear panel with the 100M fiber port
Figure 2-1
Please refer to the following sheet for detail information.
Interface Name
Connector
Function
VIDEO OUT
Video output port
BNC
Output analog video
signal. Can connect to
