2 side panel, 3 front panel – IC Realtime 2 MegaPixel Full HD IP Box Camara (ICIPS2000) User Manual
Page 23
17
GND
Please make sure the
device is securely
earthed to prevent the
thunderstorm strike.
2.2 Side Panel
Please refer to the following interface for side panel dimension information. The unit is mm. See
Figure 2-2.
Figure 2-2
2.3 Front Panel
Please refer to the following interface for the front panel information. The unit is mm. See Figure
2-3.
