12
SCAN NO ： 001
SET LEFT LIMIT
SET RIGHT LIMIT
SCAN SPEED ：5
RUN
STOP
BACK EXIT
Move the cursor to SCAN button and then click confirm button.
z SCAN NO ：Here is to set auto scan number. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
z SET LEFT LIMIT ：Here is to set camera left address. Click confirm button to save current setup.
z SET RIGHT LIMIT ：Here is to set camera right address. Click confirm button to save current setup.
z SCAN SPEED: Please use the left/right button on the keyboard or in the speed dome terminal menu
to set.
z RUN: Please input auto scan number first, and then please move the cursor to RUN and click
confirm button to activate auto scan function.
z STOP: Here is to terminate auto scan function.
z BACK: Go back to previous menu.
z EXIT: Log out system menu.
2.4.4.4 Tour
Move the cursor to highlight TOUR item and then click confirm button to go to set interface.
z TOUR NO ：Here is to ser tour number. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
z TOUR SETTING: Move the cursor to TOUR setting item and then click confirm button. You can see
the following interface. Here you can add or remove the preset, and set the corresponding dwell
time and call speed.
„ DWELL: Here is t set dwell time. Please use the left/right button on the keyboard or in the
speed dome terminal menu to set.
„ SPEED: Here you can set the speed value.
When you move the cursor to one tour number, you can use left/right button to turn the page.
When you move the cursor to one tour number, please click confirm button to set the tour. Please use
up/down button to set preset number, dwell time and speed. Use the left/right button to go to the next
TOUR NO： : 1
TOUR SETTING
DELETE TOUR
RUN
STOP
BACK EXIT
NO PRESET DWELL SPEED
01 000 005 013
02 000 005 013
03 000 005 013
… … … …
32 000 005 013
BACK EXIT
