13
z AE MODE: Here you can set the camera exposure mode. It includes: auto/manual/AV (iris priority)/TV
(shutter priority). Please use the left/right button on the keyboard or in the speed dome terminal menu to
set.
o
Auto: It becomes valid after you set the exposure compensation, backlight compensation
(BLC), slow shutter, wide dynamic region (WDR).
o
Manual: It becomes valid after you set the gain setting, shutter, iris setting, wide dynamic
region (WDR).
o
AV: It becomes valid after you set the exposure setting, iris setting, wide dynamic region
(WDR).
o
TV: It becomes valid after you set the shutter setting, exposure compensation, wide dynamic
region (WDR).
z GAIN SETTING: It is to adjust the gain. It has several levels. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
z SHUTTER: You can set shutter speed here. It has several levels. Please use the left/right button on the
keyboard or in the speed dome terminal menu to set.
z IRIS SETTING: It is to set iris. It has several levels. Please use the left/right button on the keyboard or
in the speed dome terminal menu to set.
z EXPOSURE COM: It is to set exposition mode. It has several levels. Please use the left/right button on
the keyboard or in the speed dome terminal menu to set.
z SLOW AE: In the strong light environment, you can lower the camera exposure speed to capture the
image and enhance the definition. The value ranges from 1 to 16. The bigger the value, the higher the
exposure speed. Please use the left/right button on the keyboard or in the speed dome terminal menu
to set.
z SLOW SHUTTER: In lower illumination environment, you can lower the cameras auto exposure time to
capture the image and enhance the definition. Please note for the moving object, the image trail
phenomenon may occur.
Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
z WDR ENBALE: It is an abbreviation for wide dynamic region. Please make sure your camera supports
current function. This function can adjust the video brightness when the contrast between the strong
light and the dark light is too high. Please use the left/right button on the keyboard or in the speed dome
terminal menu to set.
z NEXT PAGE: It includes: BLC, GAIN LIMIT, SLOW SHUTTER LOW LIMIT, NOISE REDUCTION, 3D
NOISE REDUCTION. Move the cursor to the item and then click the left/right button to set.
o
BLC: It is an abbreviation for back light compensation. System can compensate the object in
the dark light to achieve a clear video. Please use the left/right button on the keyboard or in
the speed dome terminal menu to set.
o
GAIN LIMIT: It is to control the camera gain. The video noise may be too high if the gain
value is large in the low illumination.
AE MODE : AUTO
GAIN SETTING : 02
SHUTTER : 1/50
IRIS SETTING : 11
EXPOSURE COM : 08
SLOW AE : 01
SLOW SHUTTER ON
WDR ENBALE : OFF
NEXT PAGE
BACK
EXIT
BLC :ON/OFF
GAIN LIMIT : 08
SLOW SHUTTER LIMIT : 1/12
NOISE REDUCTION : 03
3D NOISE CONTROL : ON/OFF
BACK
EXIT
