6

7

4. Package

5. Special features of the model

Camera x 1

manual x 1

Extra video output cable

x 1

L- Wrench Ø4.0 x 1

Tapping screws x3

Plastic anchor x3

* Higher resolution of 600TVL(D)/650TVL(N)

This unit has come up with an innovative way of increasing cubic resolution to more
than 30% higher than that of conventional 600TVL cameras.
It upgrades horizontal resolution to 600TVL and vertical resolution to 540TVL so that the
cubic resolution becomes 324KTVL while conventional cameras provide only 240KTVL.

* Unbeatable WDR Performance

This unit provides a very unique and far superior image scanning capability of defining
the details of differently contrasted areas compared with any other conventional WDR
cameras. With current WDR technologies, defining images in shaded areas are typically
not clear enough with over-exposed picture quality. This camera provides a special
resolution to intelligently analyze the exposure ratio and to optimize it into an unbeatably
clear image quality.

* Super Low Light sensitivity

The system specifies itself as the best resolution in the market that overcomes the
limitation of compromising light sensitivity from conventional WDR cameras.
With its special technology, it provides remarkable low light sensitivity of 0.1Lux /F2.0 ~
0.0001Lux w /Sens-up 512x which is at least 3 times better than any other conventional
WDR cameras.

* 2D/3D Noise Reduction

2D/3D DNR achievement is another reference in new WDR technology.
It reproduces noiseless images with 2D/3D filtering Noise Reduction Technology so that
users can save the volume of storage media and HDD capacity in DVR.
2D DNR helps preserved edged in the picture, while 3D DNR realizes clear images with
no ghost effect.

* DIS (Digital Image Stabilizer)

This technology reduces blurring associated with the motion of the subject by using
pixels outside the border of the visible frame to provide a buffer for the motion.
Increasing the exposure time without blurring the image makes the moving subject
stabilized digitally.

With an operation of a wide dynamic range camera in an environment with a fluorescent
lighting, an effect that is called “color rolling” usually happens due to the lack of the
synchronization between the camera and the neon light.
New WDR technology tracks the light changes relative to the camera and adapts its own
timing to the periodicity of fluorescent illumination to the sample light at a constant
phase, virtually elimination the color rolling effect.

* Anti-Color Rolling

WideLux Super Night Vision
Outdoor Camera

INSTRUCTION MANUAL

· EL2000

Please read this manual carefully before installation and operation of the product.
