IF USING MOTRONIC OR RELUCTOR PICK-UP READ APPENDIX E 2.3
“ADJUSTING THE ON-BOARD JUMPERS”
1.3.15 Connect the ECU
The ECU can now be connected and tested. Be sure to engage the clip on the main connector.
This will make sure the main connector parts mate correctly and reduces the mechanical strain
on the connector bodies. The system can now be tested as described in the following chapters.
