Great Planes Spirit Elite 2-Meter Sailplane Kit - GPMA0535 User Manual
Page 26
26
Step 24
1" [25.4mm]
THREADED WIRE
INNER PUSHROD TUBE
NYLON CLEVIS AND
CLEVIS RETAINER
Step 25
1" [25.4mm]
THREADED WIRE
METAL CLEVIS
NYLON BACKPLATE
NYLON CONTROL HORN
2-56 X 3/8" [9.5mm] BOLT
2-56 X 3/8" [9.5mm] BOLT
Wrap the receiver and
battery in foam.
Line up the control horns
with the pushrods. Attach
the control horns to the
elevator and rudder.
Install the switch inside the
fuselage, next to the receiver.
Step 23
