Engine and suitable propellers
❏
4-Channel radio with 6 standard servos
❏
(2) 12" [300mm] Servo extension (HCAM2711 for Futaba ® )
❏
(2) Y-harnesses (HCAM2751 for Futaba)
❏
1/4" [6mm] R/C foam rubber (HCAQ1000)
❏
(2) 4 oz. [120cc] Fuel tank (GPMQ4101)
❏
3' [900mm] Standard silicone fuel tubing (GPMQ4131)
❏
#64 Rubber bands (1/4 lb [113g] box, HCAQ2020)
❏
(1) 2" [51mm] Nose wheel (GPMQ4221)
❏
(2) 2-1/2" [64mm] Main wheels (GPMQ4223)
❏
(2) 2" [51mm] White spinner (GPMQ4510)
❏
(2) Rolls covering film (if covering in one color), box
cover model was covered with:
Aluminum (TOPQ0205)
Black (TOPQ0208)
White (TOPQ0204)
Cub Yellow (TOPQ0220)
Olive Drab (TOPQ0210)
In addition to common household tools (screwdrivers, drill,
etc.), this is the “short list” of the most important items
required to build the Profile 38.
We recommend Great
Planes Pro ™ CA and Epoxy glue.
❏
1 oz. [30g] Thin Pro CA (GPMR6002)
❏
1 oz. [30g] Medium Pro CA+ (GPMR6008)
❏
Pro 30-minute epoxy (GPMR6047)
❏
Pro 6-minute epoxy (GPMR6045)
❏
HobbyLite ™ balsa-colored balsa filler (HCAR3401)
❏
Plan Protector ™ (GPMR6167) or wax paper
❏
Drill bits: 1/16" [1.6mm], 3/32" [2.4mm], 7/64" [2.8mm],
1/8" [3.2mm], 5/32" [4mm], 3/16" [4.8mm],
❏
Small metal file
❏
Stick-on segmented lead weights (GPMQ4485)
❏
Silver solder w/flux (GPMR8070)
❏
#1 Hobby knife (HCAR0105)
❏
#11 Blades (100-pack, HCAR0311)
❏
Single-edge razor blades (10-pack, HCAR0212)
❏
Small T-pins (100, HCAR5100)
❏
Medium T-pins (100, HCAR5150)
❏
Sanding tools and sandpaper assortment (see Expert
Tip–Easy-Touch ™ Bar Sander section on page 5)
❏
Top Flite ® MonoKote ® sealing iron (TOPR2100)
or
❏
21st Century ® sealing iron (COVR2700)
❏
Top Flite Hot Sock ™ iron cover (TOPR2175)
or
❏
21st Century iron cover (COVR2702)
❏
Top Flite MonoKote trim seal iron (TOPR2200)
or
❏
21st Century trim seal iron (COVR2750)
❏
Top Flite MonoKote heat gun (TOPR2000)
Here is a list of optional tools mentioned in the manual that
will help you build the Profile 38.
❏
Pro Aliphatic resin (2 oz. [60g], GPMR6160)
❏
2 oz. [57g] Spray CA activator (GPMR6035)
❏
4 oz. [113g] Aerosol CA activator (GPMR634)
❏
CA applicator tips (HCAR3780)
❏
CA debonder (GPMR6039)
❏
Kyosho ® masking film (KYOR1040)
❏
Epoxy brushes (6, GPMR8060)
❏
Mixing sticks (50, GPMR8055)
❏
Mixing cups (GPMR8056)
❏
Razor plane (MASR1510)
❏
Builder’s triangle set (HCAR0480)
❏
Metal template set (30°/60°/90° and 45° triangles,
HCAR0500)
❏
Scale warbird template (TOPQ2187)
❏
36" Metal ruler (HCAR0475)
❏
Curved-tip canopy scissors (for trimming plastic parts,
(HCAR0667)
❏
Pliers with wire cutter (HCAR0630)
❏
Robart Super Stand II (ROBP1402)
❏
18" x 24" [460 x 610mm] Builder’s cutting mat
(HCAR0455)
❏
16" x 48" [410 x 1220mm] Building board (GPMR6950)
❏
Hobbico ® Duster ™ can of compressed air (HCAR5500)
❏
Masking tape (TOPR8018)
❏
Threadlocker ™ thread locking cement (GPMR6060)
❏
Denatured alcohol (for epoxy clean up)
❏
Panel Line Pen (TOPQ2510)
❏
Z-bend pliers (HCAR2000)
❏
Rotary tool such as Dremel ® Moto-Tool ®
❏
Rotary tool reinforced cut-off wheel (GPMR8200)
❏
Servo horn drill (HCAR0698)
❏
Hobby Heat ™ micro torch (HCAR0750)
❏
Dead Center ™ Engine Mount Hole Locator (GPMR8130)
❏
AccuThrow ™ Deflection Gauge (GPMR2405)
❏
Slot Machine ™ hinge slotting tool (110V, GPMR4010)
❏
CG Machine ™ (GPMR2400)
❏
Laser incidence meter (GPMR4020)
❏
Precision Magnetic Prop Balancer ™ (TOPQ5700)
Optional Supplies & Tools
Covering Tools
Adhesives & Building Supplies
Required Accessories
REQUIRED ITEMS
