Page 4: Kit inspection

4
Battery Pack & Accessories
The following battery pack is recommended. Note: The
1600mAh pack weighs approximately 5oz [142g] and should
balance this model without requiring nose ballast weight. If
you are using batteries other than the one recommended
here, please be sure that your battery is capable of delivering
15A safely.
•
ElectriFly LiPo 1600mAh 11.1V 20C Discharge w/
Balance (GPMP0719)
A LiPo-compatible charger is required for these batteries,
along with a cell balancer. We recommend:
•
ElectriFly Equinox
™
1-5 cell LiPo cell balancer
(GPMM3160)
•
ElectriFly PolyCharge4
™
LiPo battery charger
(GPMM3015)
OR
•
ElectriFly PolyCharge
™
DC LiPo battery charger
(GPMM3010)
Required Adhesive and
Building Supplies
This is the list of adhesive and building supplies required to
fi nish the Nieuport 11 EP.
•
1/2 oz. [15g] Thin Pro CA (GPMR6001)
•
1/2 oz. [15g] Medium Pro CA+ (GPMR6007)
•
R/C-56 Glue 4oz (JOZR5007)
•
Denatured alcohol
•
Drill bits: #55 [1.3mm], #57 [1.1mm], 1/16" [1.6mm]
•
#1 Hobby knife (HCAR0105)
•
#11 blades (5-pack, HCAR0211)
•
Hobbico
®
Steel T-Pins 1" (100) (HCAR5100)
•
Great Planes Pro Thread Locker (GPMR6060)
•
CA applicator tips (HCAR3780)
•
220 grit sandpaper
•
Bru Line hemostat – curved 5-1/2" (BRUR1303)
•
Retractable fabric tape measure (HCAR0478)
Optional Supplies and Tools
Here is a list of optional tools mentioned in the manual that
will help you build the Nieuport 11 EP.
•
21
st
Century
®
sealing iron (COVR2700)
•
21
st
Century iron cover (COVR2702)
•
2 oz. [57g] spray CA activator (GPMR6035)
•
4 oz. [113g] aerosol CA activator (GPMR634)
•
Great Planes® Hook and Loop material
(GPMQ4480)
•
Great Planes Heat Shrink Tubing 3/8" x 3" [76mm]
(GPMM1060)
•
Electrical tape
•
Masking tape
•
CA debonder (GPMR6039)
•
Great Planes Double-Sided Servo Tape 1" x 3'
(GPMQ4442)
•
Panel Line Pen (TOPQ2510)
•
Rotary tool (Dremel
®
) with cutoff wheel
•
Hobbico Flexible 18" Ruler Stainless Steel
(HCAR0460)
•
Builder’s Triangle Set (HCAR0480)
•
AccuThrow
™
Defl ection Gauge (GPMR2405)
•
Hobbico 12 Volt DC power supply (HCAP0250)
•
Green 3M
®
Scotch Brite
™
IMPORTANT BUILDING NOTES
•
When you see the term test fi t in the instructions, it means
that you should fi rst position the part on the assembly
without using any glue, then slightly modify or custom fi t
the part as necessary for the best fi t.
•
Whenever the term glue is written you should rely upon
your experience to decide what type of glue to use. When
a specifi c type of adhesive works best for that step, the
instructions will make a recommendation.
•
Photos and sketches are placed before the step they
refer to. Frequently you can study photos in following
steps to get another view of the same parts.
•
The stabilizer, wing incidences, and motor thrust angles
have been factory-built into this model. However, some
technically-minded modelers may wish to check these
measurements anyway. To view this information visit the
web site at www.greatplanes.com and click on “Technical
Data.” Due to manufacturing tolerances which will have
little or no effect on the way your model will fl y, please
expect slight deviations between your model and the
published values.
•
The Nieuport 11 EP is factory-covered with Top Flite
MonoKote
®
fi lm. Should repairs ever be required, MonoKote
can be patched with additional MonoKote purchased
separately. MonoKote is packaged in six-foot rolls, but
some hobby shops also sell it by the foot. If only a small
piece of MonoKote is needed for a minor patch, perhaps a
fellow modeler would give you some. MonoKote is applied
with a model airplane covering iron, but in an emergency
a regular iron could be used. A roll of MonoKote includes
full instructions for application. Following are the colors
used on this model and order numbers for six foot rolls.
Aluminum TOPQ0205
True Red TOPQ0227
Royal Blue TOPQ0221
Jet White TOPQ0204
KIT INSPECTION
Before starting to build, take an inventory of this kit to make
sure it is complete, and inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not of
acceptable quality, or if you need assistance with assembly,
