3
3. You must take time to build straight, true and strong.
4. You must use an R/C radio system that is in fi rst-class
condition, and a correctly sized motor and components
throughout the building process.
5. You must correctly install all R/C and other components
so that the model operates correctly on the ground and in
the air.
6. You must check the operation of the model before every
fl ight to insure that all equipment is operating and that the
model has remained structurally sound. Be sure to check
clevises or other connectors often and replace them if they
show any signs of wear or fatigue.
7. If you are not an experienced pilot or have not fl own
this type of model before, we recommend that you get the
assistance of an experienced pilot in your R/C club for
your fi rst fl ights. If you’re not a member of a club, your local
hobby shop has information about clubs in your area whose
membership includes experienced pilots.
8. While this kit has been fl ight tested to exceed normal use,
if the plane will be used for extremely high stress fl ying, such
as racing, or if a motor larger than one in the recommended
range is used, the modeler is responsible for taking steps to
reinforce the high stress points and/or substituting hardware
more suitable for the increased stress.
We, as the kit manufacturer, provide you with a top quality,
thoroughly tested kit and instructions, but ultimately the
quality and fl yability of your fi nished model depends
on how you build it; therefore, we cannot in any way
guarantee the performance of your completed model,
and no representations are expressed or implied as to the
performance or safety of your completed model.
Remember: Take your time and follow the instructions to end
up with a well-built model that is straight and true.
LITHIUM BATTERY
HANDLING & USAGE
WARNING!! Read the entire instruction sheet included with
the battery. Failure to follow all instructions could cause
permanent damage to the battery and its surroundings, and
cause bodily harm!
•
ONLY use a LiPo approved charger.
•
NEVER charge in excess of 4.20V per cell.
•
ONLY charge through the “charge” lead. NEVER charge
through the “discharge” lead.
•
NEVER charge at currents greater than 1C.
•
ALWAYS set charger’s output volts to match battery volts.
•
ALWAYS charge in a fi reproof location.
•
NEVER trickle charge.
•
NEVER allow battery temperature to exceed 150°F (65°C).
•
NEVER disassemble or modify pack wiring in any way or
puncture cells.
•
NEVER discharge below 3.0V per cell
•
NEVER place on combustible materials or leave
unattended during charge or discharge.
•
ALWAYS KEEP OUT OF REACH OF CHILDREN.
REQUIRED ITEMS
This is a partial list of items required to fi nish the Nieuport 11
EP. Order numbers are provided in parentheses.
Radio Equipment
A 4-channel radio system with four micro servos and a micro
receiver are required for this plane. Many radio systems are
suitable, but we have chosen the following for this build-up.
•
(4) Futaba
®
S3114 Micro HT Servo (FUTM0414)
OR
•
(4) minimum 20 oz-in torque micro servos
•
Servo Mounting Screws (FUTM2250)
•
Futaba R617FS 7-channel 2.4GHz Receiver
OR
•
Futaba R114F FM Micro Receiver
(Low Band – FUTL0442, High Band – FUTL0443)
•
Futaba FM Single Conversion Short Crystal
(Low Band – FUTL62**, High Band – FUTL63**)
•
(1) Y-harness
(FUTM4130 or FUTM4135 for digital servos)
Motor, ESC & Propeller
Recommendations
The Nieuport 11 EP was tested extensively to fi nd the best
“power package” that offers light weight, long fl ight time, and
excellent thrust. The order numbers are provided below.
•
Great Planes RimFire
™
400 (28-30-950) Brushless
Outrunner Motor (GPMG4560)
•
ElectriFly
™
Silver Series 25A Brushless ESC 5V/2A
BEC (GPMM1820)
•
ElectriFly 10x4.5 PowerFlow™ Propeller
(GPMQ6660) (draws 15 amps max.)
OR
•
APC 11x3.8 Slo-Flyer Propeller (APCQ5017) (draws
15 amps max.)
•
ElectriFly 3.5mm Male/2.5mm Female Bullet
Connector Adapter (GPMM3122)
•
ElectriFly 3mm to 5mm Prop Adapter (GPMQ4959)
