Great Planes Gee Bee R-1 EP Rx-R - GPMA6020 - Manual (Page 6)

6
INSTALL THE MAIN LANDING GEAR
❏ ❏
1. Set the right main landing gear wire in the plastic
landing gear mount, in the wing. The two slots in the wheel
pant go towards the wing tip.
❏ ❏
2. For better access to the main landing gear wire,
carefully remove the outside of the wheel pant. The wheel
pants are held together with magnets.
❏ ❏
3. Press the main landing gear wire into the landing
gear mounts.
❏ ❏
4. Re-install the outside wheel pant half.
❏
5. Return to step 1 and install the left main gear.
RADIO SETUP
❏
1. Cut three pieces of the rough side of the hook and loop
material ½" [13mm] long. Attach each piece to the top of the
battery tray between the lightening holes.
❏
2. Insert the hook and loop battery strap through the slots
at the front of the battery hatch opening.
