4
ADDITIONAL ITEMS REQUIRED
Adhesives and Building Supplies
This is the list of Adhesives and Building Supplies that are
required to fi nish the Cirrus SR22 ARF:
❏
1/2 oz. [15g] Thin Pro ™ CA (GPMR6001)
❏
1/2 oz. [15g] Thick Pro CA- (GPMR6013)
❏
Threadlocker thread locking cement (GPMR6060)
❏
Drill bits: 1/16" [1.6mm], 5/64" [2mm]
❏
Small metal fi le or rotary tool
❏
Revell ® #1 Light Duty Aluminum Handle Knife w/Blade
(RMXR6901)
❏
Revell #11 Light Duty Blades (5) (RMXR6930)
❏
Medium T-pins (100, HCAR5150)
❏
Top Flite ® MonoKote ® sealing iron (TOPR2100)
❏
Top Flite Hot Sock ™ iron cover (TOPR2175)
❏
220 grit sandpaper
❏
Panel Line Pen (TOPQ2510)
Optional Supplies and Tools
Here is a list of optional tools that will help you build the
Cirrus SR22 ARF:
❏
1/2 oz. [15g] Medium Pro CA+ (GPMR6007)
❏
2 oz. [57g] spray CA activator (GPMR6035)
❏
4 oz. [113g] aerosol CA activator (GPMR6034)
❏
CA applicator tips (HCAR3780)
❏
CA debonder (GPMR6039)
❏
Pro 6-minute epoxy (GPMR6045)
❏
Pro 30-minute epoxy (GPMR6047)
❏
Epoxy brushes 6, (GPMR8060)
❏
Mixing sticks (GPMR8055)
❏
Mixing cups (GPMR8056)
❏
Pliers with wire cutter (HCAR0630)
❏
Rotary tool reinforced cut-off wheel (GPMR8020)
❏
Hobby Heat ™ micro torch II (HCAR0755)
❏
Precision Magnetic Prop Balancer (TOPQ5700)
❏
AccuThrow ™ Defl ection Gauge (GPMR2405)
❏
CG Machine ™ (GPMR2400)
❏
Hobbico Flexible 18" Ruler Stainless Steel (HCAR0460)
❏
Top Flite MonoKote heat gun (TOPR2000)
❏
Hobbico Pin Vise 1/16 Collet w/6 Bits (HCAR0696)
❏
Great Planes Heat Shrink Tubing 3/8x3" (3) (GPMM1060)
❏
Woodland Scenics Low Temp Foam Glue Gun
(WOOU1445)
❏
Denatured alcohol (for epoxy clean up)
Building Stand
A building stand or cradle comes in handy during the build.
We use the Robart Super Stand II (ROBP1402) for all our
projects in R&D, and it can be seen in pictures throughout
this manual.
IMPORTANT BUILDING NOTES
• When you see the term test fi t in the instructions, it means
that you should fi rst position the part on the assembly without
using any glue, then slightly modify or custom fi t the part as
necessary for the best fi t.
• Whenever the term “glue” is written, you should rely upon
your experience to decide what type of glue to use. When
a specifi c type of adhesive works best for that step, the
instructions will make a recommendation.
• Photos and sketches are placed before the step they refer
to. Frequently you can study photos in following steps to get
another view of the same parts.
• The Cirrus SR22 is factory-covered with Top Flite Jet White
MonoKote fi lm (TOPQ0204). Should repairs ever be required,
MonoKote can be patched with additional MonoKote
purchased separately. MonoKote is packaged in six-foot rolls,
but some hobby shops also sell it by the foot. If only a small
piece of MonoKote is needed for a minor patch, perhaps a
fellow modeler would give you some. MonoKote is applied
with a model airplane covering iron, but in an emergency a
regular iron could be used. A roll of MonoKote includes full
instructions for application.
• The stabilizer and wing incidences and engine thrust angles
have been factory-built into this model. However, some
technically-minded modelers may wish to check these
measurements anyway. To view this information visit the web
site at www.greatplanes.com and click on “Technical Data.”
Due to manufacturing tolerances which will have little or no
effect on the way your model will fl y, please expect slight
deviations between your model and the published values.
