11
Install the Rudder
❏
1. Install three hinges into the rudder using the same
techniques used on the ailerons and elevators and then install
the rudder to the fi n post.
❏
2. Apply three drops of thin CA to each side of each of
the rudder hinges. Allow the glue to harden. Test pull the
rudder hinges.
Install the Tail Wheel Assembly
❏
1. Locate the components of the tail wheel wire assembly.
Glue the nylon tail gear bushing in the hole in the aft bottom
of the fuse.
❏
2. Insert a pin through the hole in the nylon tail wheel
stud. Glue the stud into the hole in the bottom of the rudder.
The stud should extend from the rudder approximately 3/16"
[4.8 mm]. When gluing the stud into the rudder be sure the
pin is in line with the center of the fuselage. This will assure
proper alignment for the hole. After the stud is glued in place
remove the pin.
