6
PREPARATIONS
❏
1. If you have not done so already, remove the major
parts of the kit from the box and inspect for damage. If any
parts are damaged or missing, contact Product Support at
the address or telephone number listed in the “Kit Inspection”
section on page 5.
❏
2. Use a covering iron with a covering sock on high heat
(350°F) to tighten the covering if necessary. Apply pressure
over sheeted areas to thoroughly bond the covering to
the wood.
ASSEMBLE THE WINGS
Cut Off
Unused Arms
5/64" [2mm]
❏
1. Center your aileron servos and trims with your radio
system. Test fi t four-armed servo arms onto the servos to
determine their best orientation so that the arms are closest
KIT CONTENTS
1. Fuselage
2. Wing Panels
3. Horizontal Stabilizer & Elevators
4. Wing Joiner
5. Cowl
6. Fuel Tank
7. Fixed Landing Gear
8. Spinner
9. Belly Pan
10. Nose Gear Cover
11. Retract
Servo Tray
12. Air Valve Mount
13. Pushrods
14. Horizontal
Stabilizer Tubes
15. Engine Mount
16. Outer Pushrod Tubes
1
6
2 2
4
9
10
11 12
13
14
15
16
8
7
3
5
