4
Optional Retracts
The Dirty Birdy is designed to accept both mechanical and
pneumatic retracts. If you plan to use mechanical retracts you
only need to purchase the mechanical retract set:
❍ Hobbico Mechanical Retracts 3-Gear (HCAP4000)
If you plan to install pneumatic retracts, you will need to
purchase the following items:
❍ Robart 90 Degree Nose 5/32" Wire (ROBQ1807)
❍ Robart 90 Degree Mains w/3/16" Wire (ROBQ0005)
❍ Robart Standard Deluxe Air Control Kit (ROBQ2307)
❍ Great Planes Wire Axle 2x3/16" (2) (GPMQ4282)
❍ Great Planes Plated Wheel Collars 3/16" (4)
(GPMQ4308)
ADDITIONAL ITEMS REQUIRED
Required Hardware & Accessories
This is the list of hardware and accessories required to fi nish
the Dirty Birdy. Order numbers are provided in parentheses:
❍ R/C foam rubber 1/4" [6mm] (HCAQ1000)
❍ 3' [900mm] standard silicone fuel tubing (GPMQ4131)
Adhesives and Building Supplies
This is the list of Adhesives and Building Supplies that are
required to fi nish the Dirty Birdy:
❍ 1/2 oz. [15g] Thin Pro ™ CA (GPMR6001)
❍ Pro 30-minute epoxy (GPMR6047)
❍ Threadlocker thread locking cement (GPMR6060)
❍ Denatured alcohol (for epoxy clean up)
❍ Drill bits: 1/16" [1.6mm], 5/64" [2mm], 3/32" [2.4mm],
( 13/64" [5.2mm] pneumatic retracts only)
❍ Great Planes Tap & Drill Set 6-32 (GPMR8102)
❍ Tap handle (GPMR8120)
❍ Rotary tool with cutting bit
❍ Revell
® Premium Soft Handle Knife w/Blades (5)
(RMXR6900)
❍ Top Flite ® MonoKote ® sealing iron (TOPR2100)
❍ Top Flite Hot Sock ™ iron cover (TOPR2175)
❍ Panel Line Pen (TOPQ2510)
❍ Hobbico Steel T-Pins 1" (100) (HCAR5100)
❍ Harry Higley’s 3/16" Extended Drill (HIGR1020)
❍ Small clamps
❍ Masking tape
❍ Household oil
Optional Supplies and Tools
Here is a list of optional tools that will help you build the Dirty
Birdy .60 ARF:
❍ 1/2 oz. [15g] Thick Pro CA- (GPMR6013)
❍ 1/2 oz. [15g] Medium Pro CA+ (GPMR6007)
❍ Great Planes Pro Foam Safe CA- Thick Glue 20g
(GPMR6072)
❍ 2 oz. [57g] spray CA activator (GPMR6035)
❍ 4 oz. [113g] aerosol CA activator (GPMR6034)
❍ CA applicator tips (HCAR3780)
❍ CA debonder (GPMR6039)
❍ Great Planes Pro Epoxy 6-Minute Formula 4 oz
(GPMR6042)
❍ Epoxy brushes 6, (GPMR8060)
❍ Mixing sticks (GPMR8055)
❍ Mixing cups (GPMR8056)
❍ Pliers with wire cutter (HCAR0630)
❍ T.A. Emerald Performance Duster Compressed Air
(TAEC1060)
❍ Servo horn drill (HCAR0698)
❍ Hobby Heat
™ Micro Torch II (HCAR0755)
❍ Dead Center ™ Engine Mount Hole Locator
(GPMR8130)
❍ DuraTrax ® Ultimate Body Reamer (DTXR1157)
❍ Precision Magnetic Prop Balancer (TOPQ5700)
❍ AccuThrow
™ Defl ection Gauge (GPMR2405)
❍ CG Machine™ (GPMR2400)
❍ Hobbico Flexible 18" Ruler Stainless Steel
(HCAR0460)
❍ Top Flite MonoKote trim seal iron (TOPR2200)
❍ Top Flite MonoKote heat gun (TOPR2000)
❍ Hobbico Pin Vise 1/16 Collet w/6 Bits (HCAR0696)
❍ Hobbico 8-Piece Ball Tip Hex L Wrench SAE
(HCAR0520)
❍ Hobbico 7-Piece Ball Tip Hex L Wrench Metric
(HCAR0521)
❍ Great Planes Clevis Installation Tool (GPMR8030)
