Optional Supplies and Tools

Here is a list of optional tools mentioned in the manual that
will help you build the Curtiss P-6E Hawk EP.

❍ 2 oz. [57g] spray CA activator (GPMR6035)

❍ CA applicator tips (HCAR3780)

❍ CA debonder (GPMR6039)

❍ Epoxy brushes (6, GPMR8060)

❍ Mixing sticks (50, GPMR8055)

❍ Mixing cups (GPMR8056)

❍ Threadlocker thread locking cement (GPMR6060)

❍ AccuThrow Defl ection Gauge (GPMR2405)

❍ CG Machine

(GPMR2400)

❍ 21

st

Century

®

sealing iron [COCR2700]

❍ 21

st

Century iron cover [COVR2702]

❍ Great Planes Pilot 1/7 Military Painted [GPMQ9117]

❍ GP Aluminum Safety Spinner Nut [GPMQ4631]

IMPORTANT BUILDING NOTES

● There are three types of screws used in this kit:

Sheet Metal Screws are designated by a number and a
length. For example #6

3/4" [19mm].

This is a number six screw

that is 3/4" [19mm] long.

Machine Screws are designated by a number,
threads per inch, and a length. For example

4-40

3/4" [19mm].

This is a number four screw

that is 3/4" [19mm] long with

forty threads per inch.

● When you see the term test fi t in the instructions, it means

that you should fi rst position the part on the assembly
without using any glue, then slightly modify or custom

fi t the part as necessary for the best fi t.

● Whenever the term glue is written you should rely upon

your experience to decide what type of glue to use. When
a specifi c type of adhesive works best for that step, the

instructions will make a recommendation.

Photos and sketches are placed before the step they refer

to. Frequently you can study photos in following steps to
get another view of the same parts.

KIT INSPECTION

Before starting to build, take an inventory of this kit to make
sure it is complete, and inspect the parts to make sure they
are of acceptable quality. If any parts are missing or are not
of acceptable quality, or if you need assistance with assembly,
contact Product Support. When reporting defective or missing
parts, use the part names exactly as they are written in the
Kit Contents list.

Great Planes Product Support

3002 N Apollo Drive, Suite 1 Ph: (217) 398-8970, ext. 5
Champaign, IL 61822

Fax: (217) 398-7721

E-mail: [email protected]

ORDERING REPLACEMENT PARTS

Replacement parts for the Great Planes Curtiss P-6E Hawk
are available using the order numbers in the Replacement
Parts List
that follows. The fastest, most economical service
can be provided by your hobby dealer or mail-order company.

To locate a hobby dealer, visit the Hobbico web site at www.

hobbico.com. Choose “Where to Buy” at the bottom of the menu
on the left side of the page. Follow the instructions provided
on the page to locate a U.S., Canadian or International dealer.
If a hobby shop is not available, replacement parts may also
be ordered from Tower Hobbies at www.towerhobbies.com,
or by calling toll free (800) 637-6050.

Parts may also be ordered directly from Hobby Services by
calling (217) 398-0007, or via facsimile at (217) 398-7721, but
full retail prices and shipping and handling charges will apply.
Illinois and Nevada residents will also be charged sales tax. If
ordering via fax, include a Visa

®

or MasterCard

®

number and

expiration date for payment.

Mail parts orders Hobby Services
and payments by 3002 N Apollo Drive, Suite 1
personal check to: Champaign IL 61822

Be certain to specify the order number exactly as listed in the
Replacement Parts List. Payment by credit card or personal
check only; no C.O.D.

If additional assistance is required for any reason contact
Product Support by e-mail at productsupport@greatplanes.
com, or by telephone at (217) 398-8970.

Order No.

Description

Fuselage

Top Wing

Bottom Wing

Tail Surface Set

Cowl

Landing Gear

Wheel Pants

Hatch

Cabane Set

Interplane Struts

Bracket Set

Windshield

Decals

Landing Gear Fairings

GPMA3425

GPMA3426

GPMA3427

GPMA3428

GPMA3429

GPMA3430

GPMA3431

GPMA3432

GPMA3433

GPMA3434

GPMA3435

GPMA3436

GPMA3437

GPMA3438

REPLACEMENT PARTS LIST
