Page 2

2
INTRODUCTION
The Curtiss P-6E Hawk is an iconic airplane loved by aviation
enthusiasts everywhere. The attention to detail in this airplane,
coupled with its great looks in the air and on the ground, will
impress you and those who watch it fl y!
For the latest technical updates or manual corrections to the
“Curtiss P-6E Hawk” visit the Great Planes web site at www.
greatplanes.com. Open the “Airplanes” link, and then select the
“Curtiss P-6E Hawk EP.” If there is new technical information
or changes to this model a “tech notice” box will appear in the
upper left corner of the page.
Academy of Model Aeronautics
We urge you to join the AMA (Academy of Model Aeronautics)
and a local R/C club. The AMA is the governing body of model
aviation and membership is required to fl y at AMA clubs.
Though joining the AMA provides many benefi ts, one of the
primary reasons to join is liability protection. Coverage is not
limited to fl ying at contests or on the club fi eld. It even applies
to fl ying at public demonstrations and air shows. Failure to
comply with the Safety Code (excerpts printed in the back of
the manual) may endanger insurance coverage. Additionally,
training programs and instructors are available at AMA club
sites to help you get started the right way. There are over 2,500
AMA chartered clubs across the country. Contact the AMA at
the address or toll-free phone number below:
Academy of Model Aeronautics
5151 East Memorial Drive
Muncie, IN 47302-9252
Tele. (800) 435-9262
Fax (765) 741-0057
Or via the Internet at: http://www.modelaircraft.org
IMPORTANT!!! Two of the most important things you can
do to preserve the radio controlled aircraft hobby are to avoid
fl ying near full-scale aircraft and avoid fl ying near or over
groups of people.
SAFETY PRECAUTIONS
Protect Your Model, Yourself & Others…
Follow These Important Safety Precautions
1. Your “Curtiss P-6E Hawk” should not be considered a toy,
but rather a sophisticated, working model that functions very
much like a full-size airplane. Because of its performance
capabilities, the “Curtiss P-6E Hawk”, if not assembled and
operated correctly, could possibly cause injury to yourself or
spectators and damage to property.
2. You must assemble the model according to the instructions.
Do not alter or modify the model, as doing so may result in an
TABLE OF CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Academy of Model Aeronautics . . . . . . . . . . . . . . . . . . 2
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . 2
DECISIONS YOU MUST MAKE. . . . . . . . . . . . . . . . . . . . . 3
Radio Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Receiver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Servos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Connectors. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Motor Recommendations . . . . . . . . . . . . . . . . . . . . . . . 3
Electronic Speed Control . . . . . . . . . . . . . . . . . . . . . . . 3
Propeller. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Flight Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ADDITIONAL ITEMS REQUIRED . . . . . . . . . . . . . . . . . . . 3
Required Adhesives & Building Supplies . . . . . . . . . . . 3
Optional Supplies and Tools. . . . . . . . . . . . . . . . . . . . . 4
IMPORTANT BUILDING NOTES . . . . . . . . . . . . . . . . . . . . 4
KIT INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . . 4
KIT CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
PREPARATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
ASSEMBLE THE WINGS. . . . . . . . . . . . . . . . . . . . . . . . . . 5
Install the Aileron Servos & Pushrods . . . . . . . . . . . . . 5
ASSEMBLE THE FUSELAGE . . . . . . . . . . . . . . . . . . . . . . 8
Install the Main Landing Gear . . . . . . . . . . . . . . . . . . . 8
Install the Wings, Cabanes & Struts. . . . . . . . . . . . . . . 9
Install the Tail Assembly . . . . . . . . . . . . . . . . . . . . . . . 11
Install the Elevator, Rudder Servos and Receiver . . . 13
Install the Motor, ESC and Cowl . . . . . . . . . . . . . . . . 14
Install the Wheels and Wheel Pants. . . . . . . . . . . . . . 16
Final Details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Apply the Decals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
GET THE MODEL READY TO FLY . . . . . . . . . . . . . . . . . 18
Check the Control Directions . . . . . . . . . . . . . . . . . . . 18
Set the Control Throws. . . . . . . . . . . . . . . . . . . . . . . . 19
Finish the Model. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Balance the Model (C.G.). . . . . . . . . . . . . . . . . . . . . . 19
Balance the Model Laterally. . . . . . . . . . . . . . . . . . . . 20
PREFLIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Identify Your Model . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Charge the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . 20
Range Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
MOTOR SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . 20
AMA SAFETY CODE EXCERPTS . . . . . . . . . . . . . . . . . 21
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Radio Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
CHECK LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
FLYING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Takeoff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Flight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Landing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
