5-6
Cisco XR 12000 Series Router SIP and SPA Hardware Installation Guide
OL-17438-04
Chapter 5 Installing and Removing a Shared Port Adapter
Checking the Installation
Note A Fast Ethernet interface is used in the following examples for illustrative purposes.
The following sample display shows the events logged by the system as an SIP with a Fast Ethernet SPA
was removed from module slot 3; the system then reinitializes the remaining interface processors and
marks as down the Fast Ethernet interface on the SIP that was removed from slot 3.
Router#
18:04:29: %OIR-6-REMCARD: Card removed from slot 3, interfaces disabled
18:04:30: %LINEPROTO-5-UPDOWN: Line protocol on Interface FastEthernet3/0, changed state
to down
When you reinsert the SIP, the system automatically brings up the interfaces that were up
when the SIP was removed.
Router#
18:05:00: %OIR-6-INSCARD: Card inserted in slot 3, interfaces administratively shut down
18:05:08: %LINEPROTO-5-UPDOWN: Line protocol on Interface FastEthernet3/0, changed state
to up
Note When a new SIP is inserted or when a SIP is moved to a new slot, the system recognizes the new
interfaces but leaves them in the shutdown state until you configure them and change their state to up.
The following sample display shows the events logged by the system as you insert a new SIP in module
slot 3.
Table 5-1 show Commands to Display SPA Information
Command Type of Information Provided
show running-config The router’s running configuration and interfaces available in the
system.
show hw-module subslot oir The operational status of all SPAs in the system.
show diag SPA type in that slot, number of ports, hardware revision, part
number, and EEPROM contents.
show hw-module subslot fpd FPD version information of SPAs in the system.
show version Cisco IOS software version, names and sources of configuration
files, and boot images.
Table 5-2 show Commands to Display SPA Information
Command Type of Information Provided Example
show controllers type
slot/subslot/port Network link status, register contents, and
controller chip errors. show controllers pos 2/3/0
show interfaces type
slot/subslot/port Line status and data link protocol status for a
particular SPA port. Statistics about data traffic
sent and received by the port. show interfaces pos 2/2/0
show diag slot SPA type in that slot, number of ports, hardware
revision, part number, and EEPROM contents. show diag 4
show version Cisco IOS software version, names and sources of
configuration files, and boot images. show version
