GME GR9240W User Manual
Page 2
PA G E 2
i n s t r u c t i o n m A n uA l
G r 9 2 0 0 s E r i E s
CONTENTS
gme strongly recommends that you keep this manual
in a safe place for future reference
AccEssoriEs suPPliED . . . . . . . . . . . . . . . . . . . . 2
FEAturEs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
introDuction . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Description and model Designators . . 3
control locAtions . . . . . . . . . . . . . . . . . . . . . . 4
instAllAtion . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . 5
removing and refitting the Face Panel . . . . . . 5
Handling compact Discs . . . . . . . . . . . . . . . . . 5
moisture condensation . . . . . . . . . . . . . . . . . . 5
location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Flush mounting - Gr9220 . . . . . . . . . . . . . . . . 6
Bracket mounting - Gr9240 . . . . . . . . . . . . . . 6
Flush mounting - Gr9240 . . . . . . . . . . . . . . . . 7
removing clear cover . . . . . . . . . . . . . . . . . . 7
Electrical Wiring . . . . . . . . . . . . . . . . . . . . . . . 8
Fuse replacement . . . . . . . . . . . . . . . . . . . . . 10
oPErAtion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
General Functions . . . . . . . . . . . . . . . . . . . . . 10
radio operation . . . . . . . . . . . . . . . . . . . . . . 10
cD/mP3 operation . . . . . . . . . . . . . . . . . . . . 11
conFiGurAtion mEnu tABlE . . . . . . . . . . . . . . 13
AuXiliArY inPuts & outPuts . . . . . . . . . . . . . . 14
Front Panel inputs . . . . . . . . . . . . . . . . . . . . . 14
Aux input . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
rear output . . . . . . . . . . . . . . . . . . . . . . . . . 14
oPtionAl AccEssoriEs . . . . . . . . . . . . . . . . . . . 15
Gr9200 trouBlE sHootinG GuiDE . . . . . . . . . 16
sPEciFicAtions . . . . . . . . . . . . . . . . . . . . . . . . . 17
stAnDArD communicAtions
contrAct WArrAntY . . . . . . . . . . . . . . . . . . . 18
GmE AFtEr sAlEs sErVicE . . . . . . . . . . . . . . . . 18
ACCESSORIES SupplIEd
the Gr9200 is supplied with the following
standard accessories:
• Main unit
• Rubber mounting gasket - GR9220 only
• USB adaptor
• DC/speaker cable harness
• Mounting bracket - GR9240 only
• Gimbal knobs (2) - GR9240 only
• Top and bottom cover fill strip
• Protective case for detachable face panel
• Flush mount support kit and template
• Spare flush mount screw caps (4)
• Instruction manual
Please immediately contact your point of purchase if any of
these components are missing .
