PAGE 8 I N S T R U C T I O N M A N UA L TX6200
Removing the battery pack
The battery pack is a self contained unit
which can be removed from the radio
as follows:
1. Hold the radio face down in one hand.
2. With the thumb of one hand, push the
locking tab upwards towards the top
of the radio while swinging the top
half of the battery pack away from the
radio with the other hand.
3. Once clear of the locking tab, lift
the battery upwards away from the
radio. The base of the battery pack is
retained in a slot in the metal frame
at the base of the radio.
Re-fitting the battery pack
1. Carefully position the tongue in the
base of the battery pack into the slot
in the metal frame at the base of
the radio.
2. Swing the top half of the battery pack
into place against the radio.
3. Using both thumbs (one each side of
the belt clip) press the top half of the
battery firmly onto the radio until the
locking tab clicks downward locking
the battery pack into place.
Charging the battery pack
Your TX6200 is supplied with a BCD001
rapid charger and a PS001 AC adaptor.
The rapid charger will recharge the
battery pack in around 1 hour.
To charge the battery:
1. Plug the PS001 AC adaptor into a
standard 240 Volt outlet
2. Plug the lead from the PS001 into
the charging socket on the rear of the
BCD001 radio charger.
For further information on charging your
battery and tips on conserving battery
power, see section on ‘Maintaining Your
Battery Pack’ on page 29.
DO NOT CONNECT YOUR
VEHICLE’S BATTERY (13.8 VOLTS) DIRECTLY TO THE CHARGING
SOCKET AS DAMAGE TO THE RADIO AND BATTERY PACK WILL
RESULT WHICH WILL VOID THE WARRANTY.
Push-To-Talk Key
Monitor key
Channel UP Key
Channel DOWN Key
FUNCTION Key
Call Key
F - KeyLock
Quiet Key
F - Hi/Lo Power Key
