Operating Range Under Typical Conditions:
Note: actual range depends on RF signal
absorption, reflection, and interference.
Audio Frequency Response: (+/-3dB)
70Hz~16KHz
Total Harmonic Distortion (+/-30KHz deviation
1KHz tone): <1%
Dynamic Range: >90dB A-weighted
Operating Temperature Range:
14ºF to 122ºF (-10º C to +50º C)
Note: battery characteristics may limit
this range:
300'
Bodypack Transmitter:
Gain Adjustment Range: 20dB
Input Impedance: 470K
Dimensions: 3.3" x 2.6" x 1"
(85mm H x 65mm W x 24mm D)
Weight: 3.1oz (88 g) (without batteries)
Power Requirements:
2 “AA”
alkaline or rechargeable
batteries
Battery Life:
About 6 hours
Max Audio Input Level:
0dBV to +10dBV
Batteries
Handheld Transmitter:
Max Audio input level:
Dimensions: 9.6" x 2" dia. (243mm x 50mm dia.)
Weight: 10.6oz (300 g) (without batteries)
Power Requirements: 2 “AA” size
alkaline or rechargeable batteries
Battery Life: About 6 hours
0dBV
Receiver:
Audio Output Level: (+/-30KHz deviation, 1KHz tone)
XLR connector (into 600 load) -12dBV
¼" connector (into 3K load) -18dBV
Output Impedance: XLR connector 200
¼" connector 1K
XLR output: Impedance balanced
Pin1
Ground (cable shield)
Pin2 Audio
Pin3 No Audio
Sensitivity: -94dBm for 30dB
Image Rejection: >80dB
Dimensions: 1.7" x 8.3" x 6.3"
(44mm H x 212mm W x 160mm D)
Weight: 32.5oz (920g)
Power Requirements:
12-18 V dc at 400mA, supplied by external
power supply.
System
Frequency Range: Code D 584 - 607MHZ
Code L 655 - 679 MHZ
Transmitter Output level
:
10 dBm
Band: UHF
