Specifications Specifications
System
Available Channels: 16
Frequency Range: CODE D 584~607 MHz
CODE L 655~679MHz
Transmitter Output level
:
10 dBm
Band: UHF
Operating Range Under Typical Conditions: 150' (50m)
Note: actual range depends on RF signal
absorption, reflection, and interference.
Audio Frequency Response: (+/-3dB) 60Hz~16KHz
Total Harmonic Distortion (+/-30KHz deviation，
1KHz tone): <1%
Dynamic Range: >90dB A-weighted
Operating Temperature Range:
14ºF to 122ºF (-10º C to +50º C)
Note: battery characteristics may limit this range:
Bodypack Transmitter:
Audio Input Level: 0 dBV to +10dBV
Gain Adjustment Range: 20dB
Input Impedance: 5KΩ
Dimensions: 3.3" x 2.6" x 1"
(85mm H x 65mm W x 24mm D)
Weight: 3.0oz (85 g) (without batteries)
Power Requirements:
2
alkaline or rechargeable batteries AA Batteries
Battery Life: About 8 hours
Handheld Transmitter:
Max Audio input level: 0dBV
Dimensions: 9.8" x 2.1" dia. (250mm x 53mm dia.)
Weight: 9.5oz (270 g) (without batteries)
Power Requirements: 2 “AA”size alkaline or
rechargeable batteries
Battery Life: About 8 hours
Receiver:
Audio Output Level: (+/-30KHz deviation, 1KHz tone)
XLR connector (into 600Ω load) -12dBV
¼" connector (into 3KΩ load) -18dBV
Output Impedance: XLR connector 200Ω
¼" connector 1KΩ
XLR output: Impedance balanced
Pin1：Ground (cable shield)
Pin2：Audio
Pin3：No Audio
Sensitivity: -93dBm for 30dB
Image Rejection: >90dB
Dimensions: 1.7" x 8.3" x 6.3"
(44mm H x 212mm W x 160mm D)
Weight: 31oz (880 g)
Power Requirements:
12-18 V dc at 400mA, supplied by external
power supply.
PSE L CODE
1 655.200
2 656.675
3 658.500
4 660.050
5 661.500
6 662.900
7 664.425
8 666.500
9 667.800
10 669.225
11 670.800
12 672.275
13 673.725
14 675.075
15 676.500
16 678.600
PSE D CODE
1 584.400
2 587.500
3 589.575
4 591.050
5 593.425
6 595.200
7 598.450
8 599.650
9 601.275
10 603.775
11 605.500
12 606.750
13 586.025
14 590.525
15 594.150
16 602.450
