3
Functions:
Changing Batteries:
Expected life for two alkaline batteries is about 8 hours.
If the power LED (green) turns red then the batteries are low
and should be changed immediately (as shown below).
Microphone Head.
Power LED and LOW battery indicator
(red = Low battery)
Power Switch
Infrared receiver (IR) window
Battery cover
1
2
3
4
5
HH38 Handheld Transmitter HH38 Handheld Transmitter
2
3
1
4
Open Close
5
Handheld Transmitter Setup:
The HH38 will need to be powered off and on again during the syncing
process in order to properly sync. An amber power light on the HH38
indicates that it is ready to receive the IR signal from the receiver.
