MBP85 Bodypack Transmitter MBP85 Bodypack Transmitter
Microphones for bodypack transmitter
HS-U3BK Headset Microphone
Polar Patten: Unidirectional
Sensitivity: -65dB ± 2dB
Frequency Response:
50Hz-18KHz
Output impedance: <2K Ω
S/N Ratio: <38dB
LV-U3BK Clip-on Microphone
Polar Patten: Unidirectional
Sensitivity: -64dB ± 2.2dB
Frequency Response:
100Hz-20KHz
Output impedance:2K Ω
S/N Ratio: >44dB
11
How to Wear the MBP85 Transmitter:
Clip the transmitter to belt
, or slide a guitar strap
through the transmitter's clip , as shown in the diagram at left.
For best results, slide the transmitter until the belt is pressed
against the base of the clip
.
1
2
1
This is just a sample of the
many headset options available
from Galaxy Audio.
